products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Seamless Steel Tube
Created with Pixso.

Jis G3459 Torich Cold Drawn Seamless Steel Tube Carbon

Name

Jis G3459 Torich Cold Drawn Seamless Steel Tube Carbon

Brand Name: TORICH
Model Number: JIS G3459
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Product Name:
JIS G3459 CARBON STEEL SEAMLESS TUBES
Model No:
JIS G3459
Technique:
Cold Drawn
Surface Treatment:
Oiled
Type:
Seamless
Alloy Or Not:
Non-alloy
Section Shape:
Round
Application:
For Boilers,Superheaters,Steam Linepipes Of Boilers
Packaging Details:
In wooden boxes or hexagonal bundles in seaworthy packing
Highlight:

cold drawn seamless steel tube jis g3459

,

carbon cold drawn seamless steel tube

,

torich cds tubing

Product Description

JIS G 3459 Carbon steel pipes for high pressure service



JIS G3459 Stainless Steel Pipe is used for the pipings for corrosion resistance, and different grades are applicated for low and high temperature sevice, manufacture method can be cold finished or hot finished, so wide range of specific product requirement can be satisfied to meet the customer's applications.



Chemical Composition:

Grade Chemical composition
C Si Mn P S Ni Cr Mo Others
SUS 304 HTP 0.04~0.10 0.75max. 2.00 max. 0.040 max. 0.030 max. 8.00~11.00 18.00~20.00 - -
SUS 309 STP 0.08 max. 1.00 max. 2.00 max. 0.040 max. 0.030 max. 12.00~15.00 22.00~24.00 - -
SUS 310 TP 0.15 max. 1.50 max. 2.00 max. 0.040 max. 0.030 max. 19.00~22.00 24.00~26.00 - -
0.08 max. 1.50 max. 2.00 max. 0.040 max. 0.030 max. 19.00~22.00 24.00~26.00 - -
SUS 316TP 0.08 max. 1.00 max. 2.00 max. 0.040 max. 0.030 max. 10.00~14.00 16.00~18.00 2.00~3.00 -
SUS 316HTP 0.04~0.10 0.75 max. 2.00 max. 0.030 max. 0.030 max. 11.00~14.00 16.00~18.00 2.00~3.00 -
SUS 316LTP 0.030 max. 1.00 max. 2.00 max. 0.040 max. 0.030 max. 12.00~16.00 16.00~18.00 2.00~3.00 -
SUS 316HTP 0.04~0.10 0.75 max. 2.00 max. 0.030 max. 0.030 max. 11.00~14.00 16.00~18.00 2.00~3.00 -
SUS 316TiTP 0.08 max. 1.00 max. 2.00 max. 0.040 max. 0.030 max. 10.00~14.00 16.00~18.00 2.00~3.00 Ti 5XC % min.



Mechanical properties:

Grade Tensile strength Proof stress Elongation %
kgf/mm2 {N/mm2} kgf/mm2 {N/mm2} No. 11 test piece
No. 12 test piece		 No.5 test piece No.4 test piece
Longitudinal direction Transverse direction Longitudinal direction Transverse direction
SUS 304TP 53{520}min. 21{206} min 35 min 25 min 30 min 22 min
SUS 304HTP 53{520}min. 21{206} min 35 min 25 min 30 min 22 min
SUS 304LTP 49{481}min. 18{177} min 35 min 25 min 30 min 22 min
SUS 309TP 53{520}min. 21{206} min 35 min 25 min 30 min 22 min
SUS 309STP 53{520}min. 21{206} min 35 min 25 min 30 min 22 min
SUS 310TP 53{520}min. 21{206} min 35 min 25 min 30 min 22 min
SUS 310STP 53{520}min. 21{206} min 35 min 25 min 30 min 22 min
SUS 316TP 53{520}min. 21{206} min 35 min 25 min 30 min 22 min
SUS 316HTP 53{520}min. 21{206} min 35 min 25 min 30 min 22 min
SUS 316LTP 49{481}min. 18{177} min 35 min 25 min 30 min 22 min
SUS 316TiTP 53{520}min. 21{206} min 35 min 25 min 30 min 22 min

Product Pictures:

Jis G3459 Torich Cold Drawn Seamless Steel Tube Carbon 0



Jis G3459 Torich Cold Drawn Seamless Steel Tube Carbon 1





Company Introduction:

Jis G3459 Torich Cold Drawn Seamless Steel Tube Carbon 2

Packaging and Delivery:

Jis G3459 Torich Cold Drawn Seamless Steel Tube Carbon 3

FAQ:

Q: Are you trading company or manufacturer?

A: We are a professional steel pipes materials manufacturer.



Q: How long is your delivery time?

A: Generally it takes 7-14 days if the goods are in stock or 30-60 days if there is no stock, this mainly depends on quantity.



Q: Do you provide free sampleas?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.



Q: What is your terms of payment?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us.
