Large Diameter 36 Inch 60mm Stainless Steel Welded Pipe
Product Details
60mm WT steel welded pipe
,60mm stainless steel welded pipe
,TORICH stainless steel welded pipe
TORICH Large Diameter 36 inch Stainless Steel Industrial Welded Pipe
Material Available
| Material | Grade |
| Austenitic Stainless Steel | 310S, 309S, 316L, 321, 304, 304L |
| Duplex | S32750, S32760, S31803, S32205 |
| Nickel-Based Alloy | N08904, N06600, N08825 |
| Copper Nickel Alloy | C70600, C70620 |
| Ferrite | 430, 409L |
| Other Special Material | 254SMO, 253MA |
| High-Temp Material | 310S, 309S, S30815 |
| Titanium Alloys | TA2, TA10, TC4 |
Size
| Seam Type | OD | WT |
| Single Seam | 6-914mm | 0.5-60mm |
| Double Seam | 630-1524mm | 2-80mm |
| Circular Seam | over 630mm | 2-100mm |
Density
| Grade | ρ (kg/dm³) | Calculation Formula | |
| 0Cr18Ni9 (06Cr19Ni10) SUS304 TP304 | 00Cr19Ni10 (022Cr19Ni10) SUS304L TP304L | 7.93 7.9 | W=0.02491 t(D-t) W=0.02482 t(D-t) |
| 0Cr17Ni12Mo2 SUS316 TP316 | 00Cr17Ni14Mo2 SUS316L TP316L | 8.0 | W=0.02513 t(D-t) |
Production process of JCOE large diameter straight seam welded pipe:
Steel Coil→ Re-test→ Flat Open and Transverse Shear→ Shear (Longitudinal Shear)→ Edge Planning and Milling→
Butt Welding of Plate→ Forming (Bending/Reeling)→ End Squaring&Tack Welding→ Welding Seam Cleaning→
Automatic Welding→ Radiographic Test→ Solution Treatment→ Rounding→ Straightening→ End Facing Treatment→
Hydrostatic Test→ Pickling Passivation→ Rinse and Dry→ Radiographic Test→ Finished Product Testing→ Marking→
Packing→ Finished Product Warehousing→ Shipping
Application:
Electric Power, Oil Refining, Nuclear Power, Drinking Water, Offshore Engineering&Shipbuilding, Natural Gas, Paper Making, Construction
