ASTM B188 C70600 CuNi10Fe1Mn Alloy Steel Pipe
Product Details
CuNi10Fe1Mn Alloy Steel Pipe
,C70600 Alloy Steel Pipe
,ASTM B188 Alloy Steel Pipe
C70600 CuNi10Fe1Mn Seamless Copper or Copper Nickel Alloy Tube Pipe
Keywords: Condenser tube; copper; copper alloy; evaporator; ferrule stock; heat exchanger; seamless tube;
C10100; C10200; C10300; C10800; C12000; C12200; C14200; C19200; C23000; C28000; C44300; C44400;
C44500; C60800; C61300; C61400; C68700; C70400; C70600; C70620; C71000; C71500; C71520; C71640;
C72200
| Item | Copper Nickel pipe in C70600/CuNi10FeMn/CN102
|
| Type | Straight copper pipe,Pancake coil copper pipe,Capillary copper pipe
|
| Standard | GB/T1527-2006,JIS H3300-2006,ASTM B75M,ASTMB42,ASTMB111,ASTMB395,
|
|
Material | T1,T2,C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920,
|
| Shape | Round,Square,Rectangular,Oval,half-round
|
| Round | OD:2-914mm (1/16"-36") WT:0.2-120mm(SCH5S-SCH160S)
|
| Square | Size:2*2-1016*1016mm(1/16"-40") WT:0.2-120mm
|
| Rectangular | Size:2*4-1016*1219mm(1/16"-48") WT:0.2-120mm
|
| Length | 1m,2m,3m,6m,or as required
|
| Hardness | 1/16 hard,1/8 hard,3/8 hard,1/4 hard,1/2hard,full hard,soft,etc
|
| Surface | mill,polished,bright,oiled,hair line,brush,mirror,sand blast,or as required
|
|
Application | Copper are of good heat conductibility. They are widely used for heat exchangers, radiators, coolers, electro-heat-up pipe, air conditioner and refrigerators, oil transportation, brake pipes,water pipes and gas pipes for construction,etc. |
| Chemical requirements | |||||||||||||
| Copper or copper alloy UNS No. | Copper | Tin | Al | Ni incl Co | Pb max | Fe max | Zn max | Mn max | As | Sb | Pmax | Cr | Other named elements |
| C44300 | 70.0-73.0 | 0.9-1.2 | 0.07 | 0.06 | remainder | 0.02-0.06 | |||||||
| C44400 | 70.0-73.0 | 0.9-1.2 | 0.07 | 0.06 | remainder | 0.02-0.10 | |||||||
| C44500 | 70.0-73.0 | 0.9-1.2 | 0.07 | 0.06 | remainder | 0.02-0.10 | |||||||
| C60800 | remainder | 5.0-6.5 | 0.1 | 0.1 | 0.02-0.35 | ||||||||
| C61300 | remainder | 0.20- 0.50 | 6.0-7.5 | 0.15 max | 0.01 | 2.0-3.0 | 0.1 | 0.2 | 0.015 | ||||
| C61400 | remainder | 6.0-8.0 | 0.01 | 1.5-3.5 | 0.2 | 1.0 | 0.015 | ||||||
| C68700 | 76.0-79.0 | 1.8-2.5 | 0.07 | 0.06 | remainder | 0.02-0.06 | |||||||
| C70400 | remainder | 4.8-6.2 | 0.05 | 1.3-1.7 | 1.0 | 0.30-0.80 | |||||||
| C70600 | remainder | 9.0-11.0 | 0.05 | 1.0-1.8 | 1.0 | 1.0 | |||||||
| C70620 | 86.5 min | 9.0-11.0 | 0.02 | 1.0-1.8 | 0.5 | 1.0 | 0.02 | C.05max S.02max | |||||
| C71000 | remainder | 19.0-23.0 | 0.05 | 0.50-1.0 | 1.0 | 1.0 | |||||||
| C71500 | remainder | 29.0-33.0 | 0.05 | 0.4-1.0 | 1.0 | 1.0 | |||||||
| C71520 | 65.0 min | 29.0-33.0 | 0.02 | 0.4-1.0 | 0.5 | 1.0 | 0.02 | C.05max S.02max | |||||
| C71640 | remainder | 29.0-32.0 | 0.05 | 1.7-2.3 | 1.0 | 1.5-2.5 | C.06max S.03max | ||||||
| C72200 | remainder | 15.0-18.0 | 0.05 | 0.50-1.0 | 1.0 | 1.0 | 0.30-0.70 | Si.03max Ti.03max | |||||
Referenced Documents:
B153 Test method for expansion (Pin Test) of copper and copper alloy pipe and tubing.
B154 Test method for mercurous nitrate test for copper alloys.
B170 Specification for oxygen-free electrolytic copper refinery shapes.
B224 Classification of Coppers.
B846 Terminology for copper and copper alloy.
B858 Test method for ammonia Vapor for determining susceptibility to stress corrosion cracking in copper alloys.
-
