C70600 CuNi10Fe1Mn CN102 EN12451 Copper Capillary Tube
Product Details
EN12451 Copper Capillary Tube
,C70600 Copper Capillary Tube
,ASTM B111 Copper Capillary Tube
Seamless tube copper nickel Alloy tube pipe C70600/CuNi10Fe1Mn /CN102 EN12451 CuNi10Fe1Mn capillary tube
Quick detail:
Product name:Seamless tube copper nickel Alloy tube pipe C70600/CuNi10Fe1Mn /CN102 EN12451 CuNi10Fe1Mn capillary tube
Type:Straight copper pipe,Pancake coil copper pipe,Capillary copper pipe
Grade:C70600/CuNi10Fe1Mn /CN102 EN12451 CuNi10Fe1Mn
Standard:ASTM B111 EN 12454 DIN 17660/1785 BS2871 JIS H3300 GB/T18890
Shape: Round,Square,Rectangular,Oval,half-round
Round: OD:2-914mm (1/16"-36") WT:0.2-120mm(SCH5S-SCH160S)
Square Size:2*2-1016*1016mm(1/16"-40") WT:0.2-120mm
Rectangular Size:2*4-1016*1219mm(1/16"-48") WT:0.2-120mm
Length :1m,2m,3m,6m,or as required
Hardness :1/16 hard,1/8 hard,3/8 hard,1/4 hard,1/2hard,full hard,soft,etc
Surface: mill,polished,bright,oiled,hair line,brush,mirror,sand blast,or as required
Application:
Copper are of good heat conductibility. They are widely used for heat exchangers,radiators,
coolers, electro-heat-up pipe, air conditioner and refrigerators, oil transportation, brake
pipes,water pipes and gas pipes for construction,etc.
Description:
Seamless tube copper nickel Alloy tube pipe C70600/CuNi10Fe1Mn /CN102 EN12451 CuNi10Fe1Mn capillary tube has been approval by TUV PED,CCS ,and Lloyd's ISO 9001 .
Quick delivery time
Samples are availale
Competitive price
Fast responses
Good after service
| Copper or copper alloy UNS No. | Cu | Pb | Fe | Ni | Zn | S | P | Mn | C | Sn |
| C70600 | Balance | 0.05max | 1-1.8 | 9-11 | 1.0 | 1.0max | ||||
| CW352H | Balance | 0.02max | 1.0-2.0 | 9-11 | 0.5max | 0.05max | 0.02max | 0.5-1.0 | 0.05max | 0.03max |
| CuNi10Fe1Mn | Balance | 0.02max | 1.0-1.8 | 9-11 | 0.5max | 0.05max | 5-1.0 | 0.05max | ||
| CN102 | Balance | 0.01max | 1.0-2.0 | 10-11 | 0.05max | 0.5-1.0 | 0.05max | |||
| C7060 | Balance | 0.05max | 1.0-1.8 | 9-11 | 0.5max | 0.05max | 0.2-1.0 | |||
| BFe10-1-1 | Balance | 0.02 max | 1.0-1.5 | 9-11 | 0.3max | 0.06max | 0.06max | 0.5-1.0 | 0.05max | 0.03max |
T1,T2,C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920,
TP1,TP2,C10930,C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300,
TU1,TU2,C12500,C14200,C14420,C14500,C14510,C14520,C14530,C17200,C19200,
C21000,C23000,C26000,C27000,C27400,C28000,C33000,C33200,C37000,C44300,
C44400,C44500,C60800,C63020,C65500,C68700,C70400,C70600,C70620,C71000,
C71500,C71520,C71640,C72200,etc
Related standard:
ASTM B111
Standard Specification for Copper and Copper -Alloy Seamless Condenser Tubes and Ferrule Stock
GB/T8890
Seamless copper alloy tube for condenser and heat exchanger
BS2871
Standard Specification for copper and copper alloys tubes
JIS H3300
Standard Specification for copper and copper alloy seamless pipes and tubes
DIN1785
Wrought copper and copper alloy tubes for condensers and heat exchangers
GB/T19447
Copper and copper-alloys seamless tubes with integral fins for heat exchanger
ASTM B359
Standard Specification for copper and copper alloy seamless condenser and heat exchanger tubes with integral fins
ASME SB 359
Standard Specification for copper and copper alloy seamless condenser and heat exchanger tubes with integral fins
EN12451
Standard Specification for copper and copper alloys-seamless,round tubes for heat exchangers
-
