OD114.3mm Nickel N02200 Nickel Alloy Pipe
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
IS09001 ISO14001 TS16949
Model Number:
ASTM B163
Trading Properties
Minimum Order Quantity:
0.5 tons
Price:
negotiable
Payment Terms:
L/C, T/T
Supply Ability:
60000tons per year
Product Summary
Nickel N02200 Pipes/Tubes Quick detail: OD:3.18-114.3mm WT:0.5-12mm UNS:N02200/W.Nr.2.4060 Nickel 200 Chemical composition: Alloy Ni+Co Fe C Mn Si Cu S Nickel 200 99 min 0.4 max 0.15 max 0.35 max 0.30 max 0.25 max 0.25 Max Nickel 200 Physical properties Density 8.89g/cm3 Melting point 1435-1466℃ ...
Product Details
Highlight:
Nickel N02200 nickel alloy pipe
,OD114.3mm Nickel Alloy Pipe
,OD114.3mm nickel 200 pipe
Standard:
Nickel N02200
Material:
Nickel N02200
OD:
3.18-114.3mm
WT:
0.5-12mm
Product Description
Nickel N02200 Pipes/Tubes
Quick detail:
OD:3.18-114.3mm
WT:0.5-12mm
UNS:N02200/W.Nr.2.4060
Nickel 200 Chemical composition:
| Alloy | Ni+Co | Fe | C | Mn | Si | Cu | S | ||
| Nickel 200 | 99 min | 0.4 max | 0.15 max | 0.35 max | 0.30 max | 0.25 max | 0.25 Max |
Nickel 200 Physical properties
| Density | 8.89g/cm3 |
| Melting point | 1435-1466℃ |
Nickel 200 Mechanical properties
| Alloy | Tensile strength(Mpa)Rm N/m2 | Yield strength(Mpa)RP0.2N/mm2 | Elongation A5 % |
| Nickel 200 | 415-585 | 105-310 | 35-55 |
| GB | UNS | SEW VDIUV | BS | AFNOR | |
| Incoloy 800 | NS111 | N08800 | W.Nr.1.4876 X10NiCrAlTi3220 | NA15 | Z8NC32.21 |
| Incoloy 800H | NS112 | N08810 | W.Nr.1.4958 X5NiCrAlTi31-20 | NA15(H) | |
| Incoloy 800HT | N08811 | W.Nr.1.4959 X 8 NiCrAlTi32-21 | |||
| Incoloy 825 | NS142 | N08825 | W.Nr.2.4858 NiCr21Mo | NA16 | NC21FeDu |
| Inconel 600 | NS313 | N06600 | W.Nr.2.816 NiCrl5Fe | NA14 | NC15FE |
| Inconel 601 | N06601 | W.Nr.2.4851 NiCr23Fe | NC23FeA | ||
| Inconel 625 | NO6625 | W.Nr.2.4856 NiCr22Mo9Nb
| NA21 | NC22DNb |
