Copper Embedded Max 12m C10200 Low Fin Tube

Basic Properties
Place of Origin: China
Brand Name: TORICH
Certification: ISO9001, TS16949
Model Number: GB/T19447
Trading Properties
Minimum Order Quantity: 100pcs
Price: negotiable
Supply Ability: 20000 tons/year
Tags

alloy steel seamless pipe

rectangular steel pipe

structural steel square tubing
Product Summary
TORICH Copper Embedded Low Fin Tube Products Material C10200, C11000 Etc Size Fin Thickness: 0.1-2mm; Tube OD: 8-55mm; Length: max 12m Fin Pitch Customize Surface Copper Coated End protector Plain End / Beveled End Application Oil&Gas Well Drilling, For Heat Exchanger Test Tension Test, Flaring Test...

Product Details

Highlight:

C10200 Low Fin Tube

,

Max 12m Low Fin Tube

,

C10200 copper fin tube
Product Name: Copper Embedded Low Fin Tube Products
Heat Treatment: Annealed
Technique: Cold Drawn
Material: C10200, C11000 Etc
End: Plain End/ Beveled End
Usage: Boiler Pipe
Type: Fin Tube
Shape: Round Shape
Product Description
TORICH Copper Embedded Low Fin Tube Products

Material C10200, C11000 Etc
Size Fin Thickness: 0.1-2mm; Tube OD: 8-55mm; Length: max 12m
Fin Pitch Customize
Surface Copper Coated
End protector Plain End / Beveled End
Application Oil&Gas Well Drilling, For Heat Exchanger
Test Tension Test, Flaring Test, Flange Test, Reverse Test, Hardness Test, Hydrostatic or Nondestructive Electric Test



Quick Detail:
Low Finned Tubes add short fin in the tube wall that greatly increase the surface area over smooth tube. The fins are formed into the tube wall so the outside diameter of the fins are not larger than the pre-finned smooth tube.Energy Transfer is solely focused on producing the largest variety and most complete solutions for finned tubing. Low finned tubes can be provided with a smooth or rifled tube inside surface.





Plain tube (mm)
Finned section dimensions (mm)
Ratio
De
D×t
Tp
dd
dr
di
η
mm
19×2
0.8
18.8
17
134
2.8
17.9
19×2
1
18.8
16.8
13.4
2.5
17.8
19×2
1.25
18.8
16.6
13
2.2
17.8
19×2
1.5
18.8
16.4
13
2
17.7
19×2
2
18.8
23
13
1.7
17.5
25×2.5
0.8
24.8
22.6
18.8
2.8
23.9
25×2.5
1
24.8
22.3
18.8
2.75
23.7
25×2.5
1.25
24.8
22.3
18
2.5
23.6
25×2.5
1.5
24.8
22.3
18
2.2
23.5
25×2.5
2
24.8
22
18
1.8
23.4
25×2.5
2.5
24.8
22
18
1.6
23.3
D------Outside diameter of plain end section
Dof----Diameter of top fins
Dr-----Root diameter of finned section
Di-----Inside diameter of finned section
T------Wall thickness of plain end section
Tp-----Fin pitch
De----Equivalent diameter of finned tube
L------Plain tube end length



Keywords: fin fan heat exchanger ,fin tube, fin tube boiler



Product Pictures:

Copper Embedded Max 12m C10200 Low Fin Tube 0



Copper Embedded Max 12m C10200 Low Fin Tube 1



Eddy Current Test and Ultrasonic Test:

Copper Embedded Max 12m C10200 Low Fin Tube 2



Quality Inspection in lab:

Copper Embedded Max 12m C10200 Low Fin Tube 3



Packing:

Copper Embedded Max 12m C10200 Low Fin Tube 4

QUALITY CONTROL



1. Incoming Raw Material Inspection

2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking



100% of our steel tubes are dimensionally checked
100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.
100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects

BS 633-4 Seamless Cold Drawn Steel Pipes DOM Steel Tube
