OD12.0mm Hastelloy C276 Nickel Alloy Special Steel Pipe
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
IS09001 ISO14001 TS16949
Model Number:
ASTM B622 626 619
Trading Properties
Minimum Order Quantity:
0.5 tons
Price:
negotiable
Payment Terms:
L/C, T/T
Supply Ability:
60000tons per year
Product Summary
Hastelloy C276 Nickel Alloy Seamless Steel Tubes Quick detail OD:3.18-114.3mm WT:0.5-12mm Standard:ASTM B574 BACEMR0175 ASME SB 574 ASTM B622 B626 B619 Standard:ASTM B622 ASTM B619 ASTM B626 Chemical Composition: % Ni Cr Mo Fe W Co C Mn Si P S V Min remian 20 12.5 2.0 2.5 Max 22.5 14.5 6.0 3.5 2.5 0...
Product Details
Highlight:
Hastelloy C276 Special Steel Pipe
,Hastelloy C276 Nickel Alloy Pipe
,OD12.0mm Nickel Alloy Pipe
Standard:
ASTM B622 626 619
Material:
Hastelloy C276
OD:
12.0-76.2mm
WT:
0.5-12.0mm
Denisity:
8.69g/cm3
Product Description
Hastelloy C276 Nickel Alloy Seamless Steel Tubes
Quick detail
OD:3.18-114.3mm
WT:0.5-12mm
Standard:ASTM B574 BACEMR0175 ASME SB 574 ASTM B622 B626 B619
Standard:ASTM B622 ASTM B619 ASTM B626
Chemical Composition:
| % | Ni | Cr | Mo | Fe | W | Co | C | Mn | Si | P | S | V |
| Min | remian | 20 | 12.5 | 2.0 | 2.5 | |||||||
| Max | 22.5 | 14.5 | 6.0 | 3.5 | 2.5 | 0.015 | 0.50 | 0.08 | 0.020 | 0.020 | 0.35 |
Physical Propety
Denisity:8.69g/cm3
Melting point:1325-1370℃
Mechanical properties
Tensile strength: 794Mpa min
Yeild strength:402Mpa min
Elongation:60%
Hardness(HB):195HB
Similar material
Alloy C276 UNS No.N10276
Alloy C22 UNS No.N06022
Alloy 59 UNSNo.N06259.
Alloy B2 N10665
Alloy 400 N04400
Alloy 201 N02201
Alloy 20 N08020
Alloy 825 N08825
Alloy 625 N06625
Alloy 600 N06600
Alloy 601 N06601
Alloy 800H/HT N08811
Alloy 617 N06617
Alloy X N06002
