OD76.2mm ASTM B163 Monel 400 Pipe
Product Details
OD76.2mm Monel 400 Pipe
,ASTM B163 Monel 400 Pipe
,ASTM B163 monel 400 tube
Alloy Monel 400 Nickel Alloy pipe
Quick detail:
Similar material grade :UNS:N04400 ,
DIN: NiCu30Fe W-Nr: 2.4360
GB/T: MCu-28-1.5-1.8
BS: NA 12:Ni68Cu28Fe
Size:
Tubes:OD: 1/2“ -3” 12.0-76.2mm
WT:0.02”-0.5” 0.5-12.0mm
Length: Ft 105ft 32 32mt
Pipe: NPS1/2”+-6” 21.34-168.3mm
WT:Sch10-Sch80
WT:2.11-12.7mm
Length 45ft 14mt
Heat exchanger tubes regular size:
Φ19mmx2mm,Φ25mmx2.5mm和Φ38mmx2.5mm Φ25mmx2mm and Φ38mmx2.5mm
Using small diameter tubes can increase heat transfer area per unit volume, compact structure, reduce metal consumption and improve heat transfer coefficient. It is estimated that the heat transfer area can be increased by about 40% and the metal can be saved by more than 20% by changing the heat exchange tube of the same diameter from Φ 25mm to Φ 19mm. But the small diameter fluid resistance is big, inconvenient to clean and easy to block. Generally, large diameter pipe is used for viscous or dirty fluid, while small diameter pipe is used for cleaner fluid.
Production method: Cold drawn and Cold rolled
Application:Heat exchanger,Nuclear Power,Mechanical engineer.
Chemical compostion:
Ni:63.0min
C:0.3max
Cu:28.0-34.0
SI:0.5max
Fe:2.5max
S:0.024max
Mn:2.0max
-
