Torich ASTM B622 Seamless Nickel Alloy UNS N10001 N010242 Steel Tube
Product Details
N010242 Seamless Nickel Alloy Tube
,N010242 Nickel Alloy Tube
,ASTM B622 Nickel Alloy Tube
Torich ASTM B622 Seamless Nickel Alloy UNS N10001 N010242 Steel Tube
Specification covers seamless pipe and tube of nickel and nickel-cobalt alloys(UNS N010001,UNS N10242,UNS N10665, UNS N12160,UNS N10675, UNS N10276, UNS N06455, UNS N06007,UNS N08320, UNS N06975, UNS N6002, UNS N06985, UNS N06022, UNS N 06035,etc)
Introduction:
Reference Standard:
B 829 Specification for general requirements for Nickel and Nickel Alloy seamless pipe and tube.
E 8 Test method for tension testing of metallic materials.
E 527 Practice for numbering metals and alloy in the unified numbering system (UNS)
Keywords:
Seamless tube; Seamless pipe; UNS N06002; UNS N06007; UNS N06022; UNS N06030; UNS N06035; UNS N06058; UNS N06059; UNS N06060; UNS N06200; UNS N06210; UNS N06230; UNS N06250; UNS N06255; UNS N10362; UNS N06455; UNS N06686; UNS N06795; UNS N06985; UNS N08031; UNS N08135; UNS N08320; UNS N08535; UNS N10001; UNS N10242; UNS N10276; UNS N10624; UNS N10629; UNS N10665; UNS N10675; UNS N12160; UNS R20033; UNS R30556
Mechanical Properties:
| Alloy | Tensile Strenth, min, ksi (MPa) | Yield Strength (0.2% offset), min, psi (MPa) | Elongation in 2 in. (50.8mm) or 4D, min,% |
| UNS N10001 | 100 (690) | 45 (310) | 40 |
| UNS N10665 | 110 (760) | 51 (350) | 40 |
| UNS N10675 | 110 (760) | 51 (350) | 40 |
| UNS N10629 | 110 (760) | 51 (350) | 40 |
| UNS N10624 | 104 (720) | 46 (320) | 40 |
| ...... | ... | ... | ... |
Product show:
1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking
100% of our steel tubes are dimensionally checked
100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.
100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects.
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples of carbon seamless steel tube ? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
-
