ISO9001 WT 3.5mm Inconel 625 Exhaust Tubing
Product Details
WT 3.5mm Inconel 625 Exhaust Tubing
,ISO9001 Inconel 625 Exhaust Tubing
,WT 3.5mm Inconel 625 pipe
Inconel 625 exhaust tubing
Inconel 625 is a kind of alloy with density of 8.4 g / cm3, melting point of 1290-1350 ℃, excellent resistance to inorganic acid corrosion, and excellent corrosion resistance to various corrosive media in oxidation and reduction environment.
625 alloy shows excellent corrosion resistance in many media. It has excellent resistance to pitting corrosion, crevice corrosion, intergranular corrosion and erosion in chloride medium.
Equivalent Grade
| GB/T | UNS | NB/T47047 | JIS | W.Nr |
| GH3625 | N06625 | NS3306 | NCF625 | 2.4856 |
Chemistry
| Cr | Mo | Co | Nb+Ta | Al | Ti | C | Fe | Mn | Si | P | S | Ni | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Min | 20 | 8 | -- | 3.15 | -- | -- | -- | -- | -- | -- | -- | -- | Balance |
| Max | 23 | 10 | 1 | 4.15 | .4 | .4 | .1 | 5 | .5 | .5 | .015 | .015 | Balance |
ASTM (American Society for Testing and Materials) for various products made
| Tube Welded | Sheet/Plate | Bar | Forging | Fitting | Wire | |||
|---|---|---|---|---|---|---|---|---|
| B444 | B705 | B444 | B704 | B443 | B446 | – | – | – |
Application:
- High temperature process
- Chemical and Petrochemical field
- Food field
- Power plants
Material List:
Incoloy 800, Incoloy 800H, Incoloy 825, Inconel 600, Hastelloy B, Hastelloy B2, Hastelloy C, Hastelloy C276,
Hastelloy C4, Hastelloy C22, Inconel 625, Inconel 718, Monel 400, Nickel 200
-
