Cold Hot Rolled A 168 UNS N06601 Inconel 601 Sheet

Basic Information
Place of Origin: China
Brand Name: Torich
Certification: IS09001 ISO14001 TS16949
Model Number: A 168
Minimum Order Quantity: 0.5 tons
Packaging Details: In Pallet
Delivery Time: 7-15 week days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 20000tons per year
Detail Information
Product Name: A 168 UNS N06601 Cold Rolled Hot Rolled Inconel Inconel 600 Alloy 601 Sheet Coil And Plates Material: UNS N06601
Length: As Per Customer's Requests Production: Hot Rolled Or Cold Rolled
Origin: China
High Light:

UNS N06601 Inconel 601 Sheet

,

NS N06601 inconel 601 plate


Product Description

A 168 UNS N06601 Cold Rolled Hot Rolled Inconel Inconel 600 Alloy 601 Sheet Coil And Plates



Chemical Composition

Inconel 601 Ni Fe C Mn Si Cu Cr S Al
58.0 – 63.0 Balance 0.10 max 1.0 max 0.5 max 1.0 max 21.0 – 25.0 0.015 max 1.0 – 1.7

Quick detail



Products
A 168 UNS N06601 Cold Rolled Hot Rolled Inconel Inconel 600 Alloy 601 Sheet Coil And Plates
Width
1219 1500mm
WT
0.1-25.4mm
Application
1. Steam turbine
2. aerospace
3. Cryogenic engineering
4. acidic environment
5. Nuclear engineering
Surface
Mill finish, polishing finish
Packing
waterproof paper or wooden box
Available Grade
Inconel 600/601/625/690/718/X750;
Incoloy 800/800H/800HT/825/926;
Hastelloy B-2/B3/C-2000/C-22/C-276/G-30/G35/X/S;
Haynes 188/230/556/230;
Monel 400/401/404/R405/K-500;
Nickle 200/201;
Alloy 20/28/31;
Invar 36/42;
Nitronic 30/32/33/40/50/60;
Nimonic 75/80A/90/C-263;
JIS 3463 and JIS 3459, DIN 2462, DIN 17458 and DIN 17456, GOST 9941

Features: Inconel 625 has excellent strength at temperatures up to 816℃. At higher temperatures, its strength is generally lower
than that of other solid solution strengthened alloys. Inconel 625 has good oxidation resistance at temperatures up to 980℃ and
shows good resistance to aqueous corrosion, but is relatively moderate compared to other more capable corrosion resistant alloys.


Applications: Chemical process industry and sea water application. Inconel 625 is used in short term applications at temperatures


Inconel 600
Inconel nickel-chromium-iron alloy 600 is a engineering material which require resistance to corrosion and heat. The alloy also has superb mechanical properties and presents the desirable combination of high strength and good workability. The high amount of nickel content gives the alloy resistance to corrosion by many organic and inorganic compounds and also makes it virtually immune to chloride-ion stress-corrosion cracking. Chromium confers resistance to sulfur compounds and also provides resistance to oxidizing conditions at high temperatures or in corrosive solutions. The alloy is not precipitation hardenable, it is strengthened and hardened only by cold work.
The Inconel alloy 600 is versatility has led to its use in a variety of manufaturing applications involving temperatures from cryogenic to above 2000F. The alloy is used extensively in the chemical industry like pharmacutical for its strength and corrosion resistance. Applications include bubble towers, stills, heaters, and condensers for processing of bubble towers, fatting acids, evaporator tubes, tube sheets, and flaking trays for the manufacture of sodium sulfid, and equipment for handling abietic acid in the manufacture of paper pulp.
The alloy's strength and oxidation resistance at high temperatures make it useful for many applications in the heat treating industry. It is used for retorts, muffles, roller hearths, and other furnace components and for heat treating baskets and trays. In the aeronautical field, alloy 600 material is used for a variety of engine and airframe components, which must withstand high temperatures. Examples are lock wire, exhaust liners, and turbine seals.
The alloy is also a standard material of constructing nuclear reactors. It has excellent resistance to corrosion by high purity water, and no indication of chloride-ion stress-corrosion cracking in reactor water systems has been detected. For nuclear applications, the alloy is produced to exacting specifications and is designated Inconel alloy 600T.

Inconel 800
Incoloy alloy 800 is a widely used material of construction for equipment that must have high strength and resist carburization,oxidation and other harmful effects of high-temperature exposure. (For high temperature applications requiring optimum rupture and creep properties, Incoloy alloys 800H and 800HT are used). The chromium in the alloy imparts resistance to oxidation and corrosion. The high percentage of nickel maintains an austenitic structure so that the alloy is ductile. the nickel content also contributes general corrosion, resistance to scaling and stress-corrosion cracking.
Incoloy alloy 800 is used in a variety of applications involving exposure to high temperatures and corrosive environments. It is used for heat-treating equipment such as baskets, trays and fixtures. In chemical and petrochemical processing the alloy is used for heat exchangers and other piping systems in nitric acid media especially where resistance to chloride stress-corrosion cracking is required. In nuclear power plants, it is used for steam-generator tubing. The alloy is often used in home appliances for sheathing of electric heating elements. In the production of paper pulp, digester liquid heaters are often made of alloy 800. In petroleum processing , the alloy is used for heat exchangers that air-cool the process stream.

Inconel 825

Incoloy alloy 825 is a nickel-iron-chromium alloy with additions of copper, molybdenum and titanium. The alloy's chemical composition is designed to provide exceptional resistance to many corrosive environments. The nickel content is sufficient for resistance to chloride-ion stress corrosion cracking. The nickel, in conjunction with the molybdenum and copper, also gives outstanding resistance to reducing environments such as those containing sulfuric and phosphoric acids. the molybdenum also aids resistance to pitting and crevice corrosion. The alloy's chromium content confers resistance to a variety of oxidizing substances such as nitrates, nitric acid and oxidizing salts. The titanium addition serves, with an appropriate heat treatment, to stabilize the alloy against sensitization to intergranular corrosion. The resistance of Incoloy 825 to general and localized corrosion under diverse conditions gives the alloy broad usefulness. Applications include chemical processing, pollution control, oil and gas recovery, acid production, pickling operations, nuclear fuel reprocessing and handling of radioactive wastes.
