Seamless Carbon Steel Astm A192 Boiler Tubes
Basic Properties
Place of Origin:
ZheJiang,CHINA
Brand Name:
TORICH
Certification:
ISO9001; ISO14001; TSI16949
Model Number:
ASTM A192
Trading Properties
Minimum Order Quantity:
5 Tons
Price:
negotiable
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
60000 Ton per year
Product Summary
ASTM A192 Seamless Carbon Steel Boiler Tubes For High-pressure Service Applications: For Boilers,Superheaters,Steam linepipes of boilers Technique: Cold-drawn Steel Grade/Steel Material: SA-450/SA-450M Size range: O.D. 6-168mm W.T. 1-15mm Length max 12000mm Characteristic: Good concentricity Good OD ...
Product Details
Highlight:
Steel Astm A192 Boiler Tubes
,Seamless Astm A192 Boiler Tubes
,Carbon Astm A192 Boiler Tubes
Product Name:
ASTM A192 Seamless Carbon Steel Boiler Tubes For High-pressure Service
Keyword:
Seamless Carbon Steel Tube
Standard:
ASTM A192
Application:
For Boilers,Superheaters,Steam Linepipes Of Boilers
Alloy Or Not:
Non-alloy
Technique:
Cold-drawn
Secondary Or Not:
Non-Secondary
Grade:
SA-450/SA-450M
O.D.:
6-168mm
W.T.:
1-15mm
Length:
According To Customers' Requirement
Section Shape:
Round
Usage:
Boiler Pipes
Surface Treatment:
Oiled
Product Description
ASTM A192 Seamless Carbon Steel Boiler Tubes For High-pressure Service
Applications: For Boilers,Superheaters,Steam linepipes of boilers
Technique: Cold-drawn
Steel Grade/Steel Material: SA-450/SA-450M
Size range:
| O.D. | 6-168mm |
| W.T. | 1-15mm |
| Length | max 12000mm |
Characteristic:
Good concentricity
Good OD and ID tolerance
High Precision
Stable quality
Smooth Roughness
TORICH QUALITY ASSURANCE
Chemical Composition:
| C | 0.06-0.18 |
| Mn | 0.27-0.63 |
| P | ≤0.035 |
| S | ≤0.035 |
| Si | ≤0.25 |
Mechanical proporties:
| Tensil Streghth | min ksi[Mpa] 47[325] |
| Yield Point | min ksi[Mpa] 26[180] |
| Elongation | ≥35% |
Hardness:
| Brinell Hardness | Rockwell Hardness Number | |
| WT≥0.200in(5.1mm) | WT＜0.200in(5.1mm) | |
| 137HRB | 77HRB | |
| Tolerance for OD and WT(SA-450/SA-450M) | |||||
| OD in(mm) | + | - | WT in(mm) | + | - |
| ＜1''(25.4) | 0.10 | 0.10 | ≤1.1/2''(38.1) | 20% | 0 |
| 1''～1.1''(25.4～38.1) | 0.15 | 0.15 | ＞1.1/2''(38.2) | 22% | 0 |
| ＞1.1/2''～＜2''(38.1～50.8 | 0.20 | 0.20 | |||
| 2''～＜2.1/2''(50.8～63.5) | 0.25 | 0.25 | |||
| 2.1/2''～＜3''(63.5～76.2) | 0.30 | 0.30 | |||
| 3''～＜4''(76.2～101.6) | 0.38 | 0.38 | |||
| 4''～＜7.1/2''(101.6～190.5) | 0.38 | 0.64 | |||
| ＞7.1/2～9''(190.5～228.6) | 0.38 | 1.14 | |||
Product Show:
FAQ
What is your Payment Term?
1.T/T: 30% deposit in advance, the balance 70% paid before shipment
2.30% down payment, the balance 70% paid against L/C at sight
3.Upon negotiation
Who are your customers?
1.Stockists, Distributors,Wholesalors,Agents, Traders, End Users, etc
How long will you react on our requirement?
1.Your requirement would be treated within 24 hours on weekdays. Quotations would be sent upon technical details confirmed by customer!
Any more questions about your doubts, please feel free to send us your emails or call!
