Cold Drawn Q345 EN 10305 E235 Precision Steel Tube
Product Details
E235 Precision Steel Tube
,EN 10305 Precision Steel Tube
,Q345 Seamless Hydraulic Tubing
EN 10305 E235 PRECISION SEAMLESS STEEL TUBE
| Grades | Delivery Conditions | Tensile Strength Rm (Mpa) | Yield Strength R2 (Mpa) | Elongation in the longitudinal direction Al (%) |
|---|---|---|---|---|
| E355 | +C (BK) | 540 min | / | 5 min |
| E355 | +A (GBK) | 450 min | / | 22 min |
| E355 | +N (NBK) | 3490-630 | 355 min | 22 min |
Application:
High Precision Cold Rolled Seamless Steel Tube is used in automotive industry, and in the
occasion where the high accuracy, brightness, cleanness of the tube are required.
Sizes Range:
OD:8mm-280mm, WT:1mm-15mm
Delivery Conditions:
+C Hard. No final treatment after final cold drawing.
+LC Soft. Final heat treatment is followed by a suitable drawing pass (limited reduction of area).
+SR Stress Relieved. After final cold drawing, the tubes are stress relieved in a controlled atmosphere.
+A Annealed. After final cold drawing, the tubes are annealed in a controlled atmosphere.
+N Normalized. After final cold drawing, the tubes are normalized in a controlled atmosphere.
Process:
The cold drawn seamless steel tube is produced by drawing raw hot rolled steel tube through
a die and over a mandrel plug.During this process the sizing (wall thickness, inside and outside
diameter), as well as weld integrity and surface finish is closely controlled to produce tube of the
required size and mechanical property characteristics.
Tube Finishing Options:
Our tubes can be additionally treated to achieve the exact finishes and ends needed by
customers. These are some of the additional operations that can be performed on our tube:
Drawing, Heat treatment, Bulging, Swaging, Cutting, Deburring, Vibro cleaning, Threading,
De-rusting, Chamfering, Washing.
Surface treatment: Oiled, black painted, hot dipped galvanized or phosphate coating as
required.Both ends of each crate will indicate the order no., heat no., dimensions, weight
and bundles or as requested.
Standard AND Optional Testing:
Visual and dimensional test 100%.
Eddy current test 100% acc. to EN 10246-3.
Ultrasonic test 100% acc. to EN 10246-7.
Chemical composition.
Impact test.
Mill Test Certificate:
The product is supplied with 3.1.B inspection certificate,according to the standards EN 10204
and ISO 10474.
Q: Are you a manufacturer?
A: Yes, we are manufacturers, we have our own factory, located in Zhejiang,
China. We have the leading edge in production and export, we are exactly what you need.
Q: Can we go to your factory?
A: A warm welcome, we will pick you up once we have your schedule.
Q: Can you arrange delivery?
A: Of course, we have permanent freight forwarders who can get the best prices from most shipping companies and provide professional services.
Q: How do we get a quote?
A: Please provide product specifications such as material, size, shape, etc. We can provide the best offer.
Q: How do you make our business long-term and good relationship?
A: 1. We maintain good quality and competitive prices to ensure the interests of our customers.
2. We respect every customer as our friend, no matter where they come from, we will sincerely do business with them and make friends.
-
