Cold Drawn OD 420mm WT 50mm ASTM A179 Seamless Steel Tube
Basic Properties
Place of Origin:
ZheJiang,CHINA
Brand Name:
TORICH
Certification:
ISO14001:2008,TS16949
Model Number:
ASTM A179
Trading Properties
Minimum Order Quantity:
5 Tons
Price:
negotiable
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
60000 Ton per year
Product Summary
ASTM A179 Seamless Cold-drawn Low-Carbon Steel Tubes For Heat-Exchanger and Condenser Applications: For manufacturing pipelines of boilers Vessel equipment Size range: O.D. 5-420mm W.T. 0.5-50mm Length max12000mm Steel Grade, Chemical Compositions and Mechanical Property: Standard Grade Chemical ...
Product Details
Highlight:
ASTM A179 Seamless Steel Tube
,WT 50mm Seamless Steel Tube
,OD 420mm Seamless Steel Pipe
Standard:
ASTM A179
Application:
For Boilers, Superheaters, Heat-Exchangers, Condensers
Alloy Or Not:
Non-alloy
Technique:
Cold-drawn
Secondary Or Not:
Non-secondary
Grade:
195GH P235GH P265GH 20MnNb6 16Mo3 St35.8 St45.8 15Mo3
O.D.:
5-420mm
W.T.:
0.5-50mm
Length:
According To Customers' Requirement
Section Shape:
Round
Usage:
Boiler Pipe
Surface Treatment:
Oiled
Product Description
ASTM A179 Seamless Cold-drawn Low-Carbon Steel Tubes For Heat-Exchanger and Condenser
Applications:
- For manufacturing pipelines of boilers
- Vessel equipment
Size range:
| O.D. | 5-420mm |
| W.T. | 0.5-50mm |
| Length | max12000mm |
Steel Grade, Chemical Compositions and Mechanical Property:
| Standard | Grade | Chemical Compostion | Mechanical Property | |||||||||
| C | Si | Mn | P | S | Cr | Mo | Mpa | Mpa | L | T | ||
| EN10216-2 | 195GH | ≤0.13 | ≤0.35 | ≤0.70 | ≤0.025 | ≤0.020 | ≤0.30 | ≤0.08 | 320-440 | ≥195 | ≥27 | ≥25 |
| P235GH | ≤0.16 | ≤0.35 | ≤1.20 | ≤0.025 | ≤0.020 | ≤0.30 | ≤0.08 | 360-500 | ≥235 | ≥25 | ≥21 | |
| P265GH | ≤0.20 | ≤0.40 | ≤1.40 | ≤0.025 | ≤0.020 | ≤0.30 | ≤0.08 | 410-570 | ≥265 | ≥23 | ≥20 | |
| 20MnNb6 | ≤0.22 | 0.15-0.35 | 1.00-1.50 | ≤0.025 | ≤0.020 | 500-650 | ≥355 | ≥22 | ≥20 | |||
| 16Mo3 | 0.12-0.20 | ≤0.35 | 0.40-0.90 | ≤0.025 | ≤0.020 | ≤0.30 | 0.25-0.35 | 450-600 | ≥280 | ≥22 | ≥20 | |
| DIN17175 | St35.8 | ≤0.17 | 0.10-0.35 | 0.40-0.80 | ≤0.030 | ≤0.030 | / | / | 360-480 | ≥235 | ≥25 | |
| St45.8 | ≤0.21 | 0.10-0.35 | 0.40-1.20 | ≤0.030 | ≤0.030 | / | / | 410-530 | ≥255 | ≥21 | ||
| 15Mo3 | 0.12-0.20 | 0.10-0.35 | 0.40-0.80 | ≤0.030 | ≤0.030 | / | 0.25-0.35 | 460-600 | ≥270 | ≥20 | ||
Products Show
FAQ
What is your Payment Term?
1.T/T: 30% deposit in advance, the balance 70% paid before shipment
2.30% down payment, the balance 70% paid against L/C at sight
3.Upon negotiation
Who are your customers?
1.Stockists, Distributors,Wholesalors,Agents, Traders, End Users, etc
How long will you react on our requirement?
1.Your requirement would be treated within 24 hours on weekdays. Quotations would be sent upon technical details confirmed by customer!
Any more questions about your doubts, please feel free to send us your emails or call!
