Structural EN10305-4 C45 Cold Rolled Precision Steel Tube
Basic Properties
Place of Origin:
Zhejiang China
Brand Name:
TORICH
Certification:
ISO 9001
Model Number:
Ck45
Trading Properties
Minimum Order Quantity:
2Ton
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
500 Tons Per Month
Product Summary
Cold-rolled precision steel pipe has high tolerance dimension accuracy, tollerance can be controlled at (+-0.1mm/+-0.05mm), good inner and outer surface finish, and no oxide layer on the surface. Precision cold-rolled steel pipe has excellent comprehensive performance, can withstand high pressure, ...
Product Details
Highlight:
C45 Precision Steel Tube
,Cold Rolled Precision Steel Tube
,EN10305-4 Cold Drawn Tube
Thickness:
3 - 25 Mm
Outer Diameter:
10 - 325 Mm
Application:
Structure Pipe
Certification:
BV
Alloy Or Not:
Non-alloy
Type:
Seamless Steel Pipe
Tolerance:
±10%
Surface Treatment:
Painting,oil Or According To Your Request
Product Description
Cold-rolled precision steel pipe has high tolerance dimension accuracy, tollerance can be controlled at (+-0.1mm/+-0.05mm), good inner and outer surface finish, and no oxide layer on the surface.
Precision cold-rolled steel pipe has excellent comprehensive performance, can withstand high pressure, cold bending, flattening, no cracking, no wrinkle, and can do all kinds of complex deformation and mechanical processing.
1. Standard:
EN10305-4 Cold drawn Precision Seamless Steel Pipes
2. Steel Grade:
E215,E235,E355, other materials upon agreement with customers.
3. Production method:
Cold drawing on the seamless steel tubes, to reach high accuracy on the OD and WT tolerance,
with certain heat treatment to achieve better mechanical properties for bending and pressure purposes
4. Size range:
O.D.:5-100mm W.T.:1-15mm L:max12000mm
5. Packing:
In Hexagonal Bundles, with anti-rust oil protection, with seaworthy packing
6. Deliver condition:
+NAfter the final cold drawing operation the tubes are normalized in a controlled atmosphere
Please specify the final heat treatment when sending the enquiry.
7. Inspection and testing:
Chemical analysis
Tensile test
Flattening test or Drift expanding test
Dimensional inspection
Visual examination
NDT for verification of leaking tightness
