Quality Cold drawn Bearings tubes 12M Seamless Alloy Steel Tube factory

Cold drawn Bearings tubes 12M Seamless Alloy Steel Tube

Name: Cold drawn Bearings tubes 12M Seamless Alloy Steel Tube
Brand: TORICH INTERNATIONAL LIMITED
SKU: ISO683
Price: 25,002.00 USD
Availability: InStock

Basic Properties

Place of Origin: China

Brand Name: Torich

Certification: ISO9001 TS16949

Model Number: ISO683

Trading Properties

Minimum Order Quantity: 3tons

Price: negotiable

Payment Terms: L/C, T/T

Supply Ability: 50000tons per year

Precision steel tubes destined for production of bearings Chemical Composition:GCr15 C:0.95-1.05 Mn:0.20-0.40 Si:0.15-0.35 S:≤0.020 P:≤0.027 Cr:1.30-1.65 100Cr6 C :0.95～1.05 Si:0.15～0.35 Mn:0.25～0.45 S :≤0.025 P :≤0.025 Cr:1.40～1.65 Ni:≤0.30 Cu:≤0.25 Mo:≤0.08Note:Ni+Cu≤0.50 Material S1541 GCr15 ...

Product Details

Highlight:

12M seamless alloy steel tube

,

bearings seamless alloy steel tube

Production Name: GCr15 100Cr6(1.3505) Seamless Bearing Steel Tubes

Material: S1541 GCr15 G4051 SUJ2 100Cr6(1.3505)

OD: 4-114mm

WT: 0.5-12mm

Length: 12M Max

Production Method: Cold Drawn

Surface: Smoonth

Product Description

Precision steel tubes destined for production of bearings

Chemical Composition:GCr15

C:0.95-1.05 Mn:0.20-0.40 Si:0.15-0.35 S:≤0.020 P:≤0.027 Cr:1.30-1.65

100Cr6 C :0.95～1.05 Si:0.15～0.35 Mn:0.25～0.45 S :≤0.025 P :≤0.025 Cr:1.40～1.65

Ni:≤0.30 Cu:≤0.25 Mo:≤0.08Note:Ni+Cu≤0.50

Material

S1541 GCr15 G4051 SUJ2 100Cr6(1.3505)

Standard

YB-T 4146

SKFD33

S13000

GOST801-78

Application

Automobile parts

Material S1541 GCr15 G4051 SUJ2 100Cr6(1.3505)

Characteristic

Bearing steel has high and uniform hardness and wear resistance as well as high elastic limit. Bearing steel is one of the most stringent steels in all steel production because of its strict requirements on the uniformity of chemical composition, the content and distribution of non-metallic inclusions, and the distribution of carbides. In 1976, ISO of the International Organization for Standardization (ISO) incorporated some general bearing steel numbers into the international standards, and divided the bearing steel into four categories: fully hardened bearing steel, surface hardened bearing steel, stainless bearing steel, high temperature bearing steel and a total of 17 steel grades.

Size range: OD 4-114mm WT0.5-12mm

Cold drawn Bearings tubes 12M Seamless Alloy Steel Tube 0
