Carbon Steel E235 E355 High Pressure Cold Drawn Steel Tube
Product Details
precision steel pipe
,precision seamless pipe
Din 2391 High Pressure Bright Annealing Seamless Precision E235 Steel Tube
Whether you are looking for corrosion resistance ,narrow tolerances or low processing cots ,Torich who has over 20 years' on producing Precision steel tubes,could make your purchase easy. Various material grade is available for production,You can select extremely formable,High-strength formable or an ultra-high-strength option for your application.
Quick detail:
Application : Hydraulic tubes.
Material: E235 St35 St45 St52 E355
Standard : DIN 2391 EN10305-1
Surface treatment: Galvanizing, to protect material from rust.
OD : 4- 20mm
WT :0.5-10 mm
Characteristic of High Pressure Cold Drawn Steel Tube :
1. Bright annealing treatment on steel tubes, have a clean in side and out size diameter,Besides, what is suitable
for bending any angle for your produce your production.
2. Galvanizing on tubes can bear the Salt spray test above 72 hours.
3. Steel tubes produce by cold drawn and cold rolled many times ,With a good tolerance on OD and WT.
Steel Grade and Chemical Compositions of high precision steel pipe:
| Steel Grade | C | Si | Mn | P | S | Al | |
| Steel Name | Steel Number | max | max | max | max | max | min |
| E215 | 1.0212 | 0.10 | 0.05 | 0.70 | 0.025 | 0.025 | 0.025 |
| E235 | 1.0308 | 0.17 | 0.35 | 1.20 | 0.025 | 0.025 | - |
| E355 | 1.0580 | 0.22 | 0.55 | 1.60 | 0.025 | 0.025 | - |
| Mechanical properties at room temperature | |||||||||||||
| Steel Grade | Minimum values for the delivery condition | ||||||||||||
| Steel Name | Steel Nubmer | (+Cc) | (+LCc) | (+SR) | (+Ad) | (+N) NBK | |||||||
| Rm Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | ||
| E215 | 1.0212 | 430 | 8 | 380 | 12 | 380 | 280 | 16 | 280 | 30 | 290-430 | 215 | 30 |
| E235 | 1.0308 | 480 | 6 | 420 | 10 | 420 | 350 | 16 | 315 | 25 | 340-480 | 235 | 25 |
| E355 | 1.0580 | 640 | 4 | 580 | 7 | 580 | 450f | 10 | 450 | 22 | 490-630 | 355 | 2 |
Application of high precision steel pipe :
| Fuel injection Pipe, Oil flow pipeline | Automobile and motorcycle Shock Absorber Pipe |
| Seat lifter Pipe | Hydrau-cylinder Pipe |
| Bicycle frame steel pipes | Mechanical steel pipes for auto and motor parts |
| Auto and Motorcycle Parts | Exhaust Pipe for Generator |
| High Heels Steel Pipes | Campanula Seamless Steel Pipe |
| Bike and Bicycle Frame | Hydraulic System(Oil Pipeline, Motor Engine Pipe) |
| Sewing machine and textile machine parts | Air conditioning fitting |
| Gas oil burner pipe | Oil pipe drilling |
| Auto and motor pipe fittings | Gas Spring pipe,motor casing pipe |
