Heat Exchanger Boiler GB13296 Stainless Steel Welded Pipe
Basic Properties
Place of Origin:
Zhejiang,China
Brand Name:
TORICH
Certification:
ISO 9001 ISO 14001 TS 16949
Model Number:
GB13296
Trading Properties
Minimum Order Quantity:
1 Ton
Price:
negotiable
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
10000 Ton/Year
Product Summary
GB13296 Seamless Stainless Steel Heat Exchanger Boiler Pipe Standard: GB13296 Seamless Stainless Steel Tubes For Boiler And Heat Exchanger Usage: This standard is applicable to Austenite and Ferritic seamless stainless steel tubes for boiler and heat exchanger. Production process: Seamless tube can ...
Product Details
Highlight:
stainless steel round tube
,stainless tube steel
Product Name:
TORICH GB13296 Seamless Stainless Steel Heat Exchanger Boiler Pipe
Keyword:
Stainless Steel Boiler Pipe
Standard:
GB13296,ASME SA-213
Surface:
Polishing
Material:
0Cr18Ni9,1Cr18Ni9,1Cr19Ni9,00Cr19Ni10,0Cr18Ni10Ti,0Cr18Ni11Nb
Shape:
Round Shape
OD:
6-159mm
WT:
1-14mm
Product Description
GB13296 Seamless Stainless Steel Heat Exchanger Boiler Pipe
Standard: GB13296 Seamless Stainless Steel Tubes For Boiler And Heat Exchanger
Usage: This standard is applicable to Austenite and Ferritic seamless stainless steel tubes for boiler and heat exchanger.
Production process: Seamless tube can be produced by Hot Treatment, Cold Drawing or Cold Rolling.
Note: Special steel grade is also available, according to customer request.
Permissible deviation of outside diameter and wall thickness
| Classification | Nominal size | Allowable deviation | |
| W-H | OD | ≤140 | ±1.25%D |
| >140 | ±1%D | ||
| S | ≤3 | -40%S | |
| >3~4 | -35%S | ||
| >4~5 | -33%S | ||
| >5 | -28%S | ||
| W-C | OD | 6~30 | +0.15 -0.20 |
| >30~50 | ±0.30 | ||
| >50 | ±0.75%D | ||
| S | D≤38 | +20%S | |
| D>38 | -22%S | ||
Steel grade and chemical composition
| Number | Steel grade | Chemical Composition % | ||||||||
| C | Si | Mn | P | S | Ni | Cr | Mo | Ti | ||
| 1 | 0Cr18Ni9 | ≤0.07 | ≤1.00 | ≤2.00 | ≤0.035 | ≤0.030 | 8.00~ 1.00 | 17.00~ 19.00 | — | — |
| 2 | 1Cr18Ni9 | ≤0.15 | ≤1.00 | ≤2.00 | ≤0.035 | ≤0.030 | 8.00~ 10.50 | 17.00~ 19.00 | — | — |
| 3 | 1Cr19Ni9 | 0.04~0.10 | ≤1.00 | ≤2.00 | ≤0.035 | ≤0.030 | 8.00~ 12.00 | 18.00~ 20.00 | — | — |
| 4 | 00Cr19Ni10 | ≤0.030 | ≤1.00 | ≤2.00 | ≤0.035 | ≤0.030 | 8.00~ 12.00 | 18.00~ 20.00 | — | — |
| 5 | 0Cr18Ni10Ti | ≤0.08 | ≤1.00 | ≤3.00 | ≤0.035 | ≤0.030 | 9.00~ 12.00 | 17.00~ 19.00 | — | ≥5C |
| 6 | 1Cr18Ni11Ti | 0.04~0.10 | ≤0.75 | ≤2.00 | ≤0.030 | ≤0.030 | 9.00~ 13.00 | 18.00~ 20.00 | — | 4Xc~ 0.60 |
| 7 | 0Cr18Ni11Nb | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.035 | ≤0.030 | 9.00~ 13.00 | 17.00~ 20.00 | — | — |
| 8 | 1Cr19Ni11Nb | 0.04~0.10 | ≤1.00 | ≤2.00 | ≤0.035 | ≤0.030 | 9.00~ 13.00 | 17.00~ 20.00 | — | — |
| 9 | 0Cr17Ni12Mo2 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.035 | ≤0.030 | 11.00~ 14.00 | 18.00~ 20.00 | 2.00~ 3.00 | — |
| 10 | 1Cr17Ni12Mo2 | 0.04~0.10 | ≤0.75 | ≤2.00 | ≤0.030 | ≤0.030 | 11.0~ 14.00 | 16.00~ 20.00 | 2.00~ 3.00 | — |
GB13296 Seamless Stainless Steel Tubes For Boiler And Heat Exchanger
