Square Welded 304 ASTM A554 Structural Steel Pipe

Square Welded 304 ASTM A554 Structural Steel Pipe

Brand Name: TORICH
MOQ: 1 Tons
Price: negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 60000 Tons/Year
Detail Information
Place of Origin:
CHINA
Certification:
ISO
Product Name:
TORICH Square Welded Steel Pipes Stainless Steel 304 Tube
Keyword:
Stainless Steel 304 Tube
Usage:
For Construction, Algricultrual Michinery,etc
Standard:
ASTM A554
Technique:
Welded
Length:
4000mm-12000mm
Steel Grade:
304 316
Payment:
T/T C/L
Packaging Details:
In bundles or in wooden boxes packaging.as per clients' options.
Supply Ability:
60000 Tons/Year
Highlight:

cold formed steel tube

,

structural steel square tubing

Product Description

TORICH Square Welded Steel Pipes Stainless Steel 304 Tube



Tolerance

a) Outer Diameter: +/- 0.03mm

b) Thickness: +/- 0.03mm

c) Length: +/- 0.5mm

Size

8-400mm ,17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50,

or customized

Thickness 0.2-3mm
Surface

180G, 320G, 400G Satin / Hairline 400G, 500G, 600G or

800G Mirror finish and so on.

Specification

ASTM A213,ASTM A312,ASTM A269,ASTM A778,

ASTM A790,DIN 17456,DIN 17458,JIS G3459,JIS G3463 etc

Material

TP304,TP304L,TP304H,TP304/304L,TP316,TP316L,

TP316/316L,TP310,TP317, TP317L,TP321,TP321H,TP347,TP347H,

S31803,S32205(Duplex),904L etc

Application range Decoration, construction, industrial purpose, food industry, etc.
Delivery conditions Annealed, pickled & polished.
Note We can produce other standard as the customers’ requirement.



Surface Finish of stainless steel pipe



Surface Finish Definition and Application
No.1 The surface is finished by heat treatment and pickling or processes corresponding theretoafter hot rolling
2D The finishes after cold rolling, by heat treatment, pickling or other equivalenttreatment
2B The finish after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to give an appropriate luster
NO.4 Polished with abrasive belt of grit#150~#180,have better brightness with discontinuous coarse stria
HL Polished with abrasive belt of grit#150~#320 on the NO.4 finish and has continuous streaks
4K The product have excellent brightness and prefect reflexivity can be near the mirror



Square Welded 304 ASTM A554 Structural Steel Pipe 0



-1



Torich Strength:


1. Torich is the STEEL TUBE MAKER company in China,playing a significant role in domestic market as well as international market.
2. Our products have exported to over 56 countries worldwide, winning a great fame among our customers.
3. There was no quality claim in the past 3 years.
4. First production was started since 1997, our boss worked in steel tube industry for over 10 years before started the own factory, factory engineers with over 30 years manufacturing experience, knowing well about production and inspection technology.
5. We have been exporting steel tubes since 10 years ago, and know well about international standard for steel tubes DIN/EN,ASTM,SAE,BS,GOST,JIS etc,also with great experience of International trading practices.
6. Our team take Timely action within 24 hours after receiving customers' first requirement and enquiry.
7. 100% prompt delivery in the past 3 years.
8. 100% dimensional check and 100% visual inspection on tube surfaces.
9. 100% eddy current test and ultrasonic test for detecting longitudinal and transversal defects.
10. Convenient tranportation: production location is 30 mins high speed train from Shanghai, 2 hours drive from Shanghai

What is your Guarantee?


1. SO9001:2008 and TS16949 certification, SGS, BV, TUV or other third party inspection is available.
2. High quality with competitive price.
3. Advanced technology, experienced engineer, ISO quality system for quality assurance and traceability.

Do you have agent or distributor in our country?
1. We are recruiting area agent and distributor all over the world, welcome to send us your mail or call us for detail discussion.


How is your production capability?
1. 2000 tons monthly production capacity, 5000 tons monthly trading capability
2. Prompt and Timely shipment

How to get the sample?


1. You are requested to pay for sample charges and courier charges from China to your country; and the free sample is according the product like size, steel grade and quantity, please consult our sales for details
2. Sample charges will be refunded when order is placed.

TORICH Square Welded Steel Pipes Stainless Steel 304 Tube
