OD 50.8mm 63.5mm TP304H Heat Exchanger Tubes
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
ISO 9001 TS16949
Model Number:
SA-213
Trading Properties
Minimum Order Quantity:
1ton
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
5000tons per year
Product Summary
SA-213-TP304H Seamless ferritic and austenitic alloy steel boiler, superheater, and heat exchanger tubes. 50.8mm 63.5mm Quick detail: Standard:SA213 Marterial:TP304H Application:TP304H Production method: Seamless Detail spec: Chemical Properties: Carbon: 0.04-0.10 Silicon: 0.75 max. Manganese: 2.00 ...
Product Details
Highlight:
carbon steel tube
,heat exchanger tubes
Standard:
SA-213
Material:
TP304H
OD:
50.8mm 63.5mm
Wall Thickness:
4.191mm
Length:
As Per Customer Requests
Application:
Boiler, Superheater, And Heat Exchanger
Product Description
SA-213-TP304H Seamless ferritic and austenitic alloy steel boiler, superheater, and heat exchanger tubes. 50.8mm 63.5mm
Quick detail:
Standard:SA213
Marterial:TP304H
Application:TP304H
Production method: Seamless
Detail spec:
Chemical Properties:
| Carbon: 0.04-0.10 | Silicon: 0.75 max. |
| Manganese: 2.00 | Nickel: 8.00-11.0 |
| Potassium: 0.04 | Chromium: 18.0-20.0 |
| Sulfur: 0.03 | Molybdenum: n/a |
Mechanical Properties:
Tensile Strength: ksi: 75 MPa: 517
Yield: ksi: 30 MPa: 207
Elongation in 2in. or 50mm, min. %: 35
Max. Hardness Rockwell B: 90
