Plain End Protector Stainless Steel Seamless Pipe With ASTM A269 Standard
Basic Properties
Place of Origin:
China
Brand Name:
TORICH
Certification:
SO9001:2008 ，TS16949
Model Number:
TP304/304L TP316/316L TP310
Trading Properties
Minimum Order Quantity:
1 ton
Price:
Negotiable
Payment Terms:
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability:
6000ton
Product Summary
ASTM A269 TP304/304L TP316/316L TP310 Seamless Stainless Steel Tube Size range: I.D.≥6.4mm W.T. ≥0.51mm L: according to customer requirement Steel Grade and Chemical Compositions: ASTM / UNS C (max) Si (max) Mn (max) P (max) S (max) Cr Ni Mo Ti TP304 / S30400 0.080 1.00 2.00 0.045 0.03 18.0-20.0 8.0...
Product Details
Highlight:
stainless steel round tube
,stainless tube steel
Product Name:
Stainless Steel Tube
Standard:
ASTM A269
Material:
TP304/304L TP316/316L TP310
Type:
Seamless
Terms Of Trade:
FOB Or CIF
Brand:
TORICH
Transportation:
Ocean, Air
Certificate:
ISO9001, TS16949
End Protector:
Plain
MTC:
En10204.3.2B
Product Description
ASTM A269 TP304/304L TP316/316L TP310 Seamless Stainless Steel Tube
Size range: I.D.≥6.4mm W.T. ≥0.51mm L: according to customer requirement
Steel Grade and Chemical Compositions:
| ASTM / UNS | C (max) | Si (max) | Mn (max) | P (max) | S (max) | Cr | Ni | Mo | Ti |
| TP304 / S30400 | 0.080 | 1.00 | 2.00 | 0.045 | 0.03 | 18.0-20.0 | 8.0-10.5 | ||
| TP304L / S30403 | 0.035 | 1.00 | 2.00 | 0.045 | 0.03 | 18.0-20.0 | 8.0-13.0 | ||
| TP304H / S30409 | 0.04-0.10 | 1.00 | 2.00 | 0.045 | 0.03 | 18.0-20.0 | 8.0-11.0 | ||
| TP316 / S31600 | 0.080 | 1.00 | 2.00 | 0.045 | 0.03 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |
| TP316L / S31603 | 0.035 | 1.00 | 2.00 | 0.045 | 0.03 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | |
| TP316Ti / S31635 | 0.080 | 1.00 | 2.00 | 0.045 | 0.03 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | 0.7>5x(C+N) |
| TP321 / S32100 | 0.080 | 1.00 | 2.00 | 0.045 | 0.03 | 17.0-19.0 | 9.0-12.0 | 0.7>5x(C+N) | |
| TP317L / S31703 | 0.035 | 1.00 | 2.00 | 0.045 | 0.03 | 18.0-20.0 | 11.0-15.0 | 3.0-4.0 | |
| TP347H / S34709 | 0.04-0.10 | 1.00 | 2.00 | 0.045 | 0.03 | 17.0-19.0 | 9.0-13.0 | ||
| TP309S / S30908 | 0.080 | 1.00 | 2.00 | 0.045 | 0.03 | 22.0-24.0 | 12.0-15.0 | 0.75 | |
| TP310S / S31008 | 0.080 | 1.00 | 2.00 | 0.045 | 0.03 | 24.0-26.0 | 19.0-22.0 | 0.75 |
Mechanical Properties:
| ASTM | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elogation (%) | Hardness (HRB) |
| 201 | ≥655 | ≥310 | ≥40 | ≤100 |
| 202 | ≥620 | ≥260 | ≥40 | ≤100 |
| 304 | ≥515 | ≥205 | ≥40 | ≤92 |
| 304L | ≥482 | ≥170 | ≥40 | ≤88 |
| 305 | ≥480 | ≥175 | ≥40 | ≤200 |
| 309S | ≥520 | ≥205 | ≥40 | ≤200 |
| 316 | ≥515 | ≥205 | ≥40 | ≤95 |
| 316L | ≥485 | ≥170 | ≥40 | ≤95 |
| 317L | ≥480 | ≥175 | ≥40 | ≤200 |
| 321 | ≥515 | ≥205 | ≥40 | ≤95 |
| 409 | ≥380 | ≥205 | ≥20 | ≤80 |
| 409L | ≥350 | ≥185 | ≥22 | ≤80 |
| 430 | ≥450 | ≥205 | ≥22 | ≤80 |
| SS329J4L | ≥620 | ≥450 | ≥18 | ≤320 |
Manufacture:
Tubes are made by seamless process.
At the manufacturer’s option,, tubing may be furnished either hot finished or cold finished.
Surface Condition:
The tubes shall be pickled free of scale,. When bright annealing is used, pickling is not necessary.
Test and Inspection:
- Mechanical Test
- Tension Test
- Flaring Test
- Flange Test
- Reverse Test
- Hardness Test
- Hydrostatic or Nondestructive Electric Test
