Name: S32205 UNS S32760 C276 Nickel Alloy Pipe ISO CE
Brand: TORICH INTERNATIONAL LIMITED
SKU: Monel Inconel Hastelloy Duplex Steel PH Steel Nickel Alloy
Price: 40,001.00 USD
Availability: InStock

Home > products > Nickel Alloy Tube >

S32205 UNS S32760 C276 Nickel Alloy Pipe ISO CE

Welded Stainless Steel Pipe

heat exchanger tubes

Place of Origin:

CHINA

Brand Name:

TORICH

Certification:

ISO CE

Model Number:

Monel Inconel Hastelloy Duplex Steel PH Steel Nickel Alloy

Request A Quote

S32205 UNS S32760 C276 Nickel Alloy Pipe ISO CE

Product Details

Ni (Min):

Balance

Resistance (μΩ.m):

Based

Ultimate Strength (≥ MPa):

783

Elongation (≥ %):

Surface:

Bright/black

Application:

Industrial,construction,etc

Highlight:

Welded Stainless Steel Pipe

heat exchanger tubes

Payment & Shipping Terms

Minimum Order Quantity

500Kg

Packaging Details

All our products are packed, stored, transported according to the international regulation.Or as customer's requirement provide special packing.

Delivery Time

4-6 Weeks

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

100 Tons Per Month

Inconel 601 Inconel Seamless Pipes Nickel Alloy For General Requirements

Get Best Price

video

Torich UNS N06600 N06601 Cold Finished Nickel Alloy ASTM B168 Steel Tube

Get Best Price

video

Torich ASTM B168 Cold Hot Finished Nickel Alloy Tubes and Tubing

Get Best Price

video

Torich ASTM B163 NO2200 Nickel Alloy Seamless Heat Exchanger Steel Tube

Get Best Price

86-574-88086983

Contact Now

Product Description

Hastelloy C / C22 / C4 seamless pipe / tube price

Material

Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy

Shape

Bar,Pipe/tube,sheet/plate,Forging,Ring,Coil,Flange,Ribbon,Square pipe/bar,product processing

Grade

Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L

Hastelloy: Hastelloy B/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g;etc

Inconel 600/601/602CA/617/625/713/718/738/X-750;ETC

Incoloy: Incoloy 800/800H/800HT/825/925/926;etc

GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044,etc

Monel: Monel 400/K500/R405,etc

Nitronic: Nitronic 40/50/60;etc

Nimonic: Nimonic 75/80A/90/A263 ;etc

Specification

Wire: 0.01-10mm

Strip: 0.05*5.0-5.0*250mm

Bar: φ4-50mm;Length 2000-5000mm

Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm

Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm

Product
Characteristics

1.According to the preparation process can be divided into deformation superalloys,
casting superalloys and powder metallurgy superalloys.

2.According to the strengthening mode, there are solid solution strengthening type, precipitation

strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc..

Inspection

ISO,SGS,BV and so on.

Packaging

All our products are packed, stored, transported according to the international regulation.Or as customer's requirement provide special packing.

hastelloy c4

Features: HASTELLOY C-4 alloy is a nickel-chromium-molybdenum alloy with outstanding high-temperature

stability as evidenced by high ductility and corrosion resistance even after aging in the 1200 to 1900°F(649 to 1038°C) range. This alloy resists the formation of grain-boundary precipitates in the weld heat-affected zone, thus making it suitable for most chemical process applications in the as-welded condition. C-4 alloy also has excellent resistance to stress-corrosion cracking and to oxidizing atmospheres up to 1900°F (1038°C).HASTELLOY C-4 alloy has exceptional resistance to wide variety of chemical process environments.

Chemical Composition

C	Cr	Mo	Fe	C	Si	Co	Mn
0.015 max	14.0-18.0	14.0-17.0	3.0 max	0.015 max	0.08 max	2.0 max	1.0 max

S	P	Ti	Ni
0.03 max	0.04 max	0.70 max	balance

Density and Melting point

Density	Melting point
8.64g/cm³	1399-1400 ℃

Mechanical Properties

Tensile strength Rm N/mm²	Yield strength R P 0. 2N/mm²	Elongation (A 5%) Min
783	365	55

S32205 UNS S32760 C276 Nickel Alloy Pipe ISO CE 0

S32205 UNS S32760 C276 Nickel Alloy Pipe ISO CE 1

S32205 UNS S32760 C276 Nickel Alloy Pipe ISO CE 2

S32205 UNS S32760 C276 Nickel Alloy Pipe ISO CE 3

S32205 UNS S32760 C276 Nickel Alloy Pipe ISO CE 4

FAQ

Q: Are you trading company or manufacturer ?

A: We are manufacturer.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: How long is your delivery time?

A: Generally it is 7-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
