Inconel 800 Tube Nickel-based Alloy Seamless Pipe For Condenser Heat Exchanger
Basic Properties
Place of Origin:
Zhejiang/China
Brand Name:
TORICH
Certification:
ISO9001 ISO 14001 TS16949
Model Number:
Inconel 800
Trading Properties
Minimum Order Quantity:
1Ton
Price:
900-1500 USD/Ton
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:
60000 Ton/Tons per Year
Product Summary
Inconel 800 Tube Nickel-based Alloy Seamless Pipe For Condenser And Heat Exchanger Material Inconel 800 is a nickel-iron-chromium alloy known for its excellent resistance to oxidation, carburization and high temperature corrosion. This material combines strength with excellent thermal stability, ...
Product Details
Highlight:
Condenser Inconel 800 Tube
,Heat Exchanger Inconel 800 Tube
Application:
Condenser And Heat Exchanger
Outer Diameter:
6-630mm
Wall Thickness:
1-100mm
Length:
6-12m,Customized
Steel Grade:
Inconel 800
Alloy Or Not:
Non-alloy,Is Alloy
Heat Treatment:
Bright Annealed
Welding Line Type:
Seamless
Product Description
Inconel 800 Tube Nickel-based Alloy Seamless Pipe For Condenser And Heat Exchanger
Material
Inconel 800 is a nickel-iron-chromium alloy known for its excellent resistance to oxidation, carburization and high temperature corrosion. This material combines strength with excellent thermal stability, making it an ideal material for seamless tubes for condensers and heat exchangers.
Specification
- Product Type: Steel pipe, nickel-based alloy steel pipe, seamless pipe
- Size: OEM For outer diameter wall thickness length
- Standards: Usually the US ASTM B163 standard is adopted, but other standards such as B409 B819 can also be used
- Finishing: Cold drawing, annealing, punching, shortening,
Chemical Composition
| Element | Min (%) | Max (%) |
|---|---|---|
| Nickel (Ni) | 30.0 | 35.0 |
| Chromium (Cr) | 19.0 | 23.0 |
| Iron (Fe) | 39.0 | 45.0 |
| Carbon (C) | - | 0.10 |
| Manganese (Mn) | - | 1.00 |
| Silicon (Si) | - | 1.00 |
| Copper (Cu) | - | 0.50 |
| Aluminum (Al) | 0.15 | 0.60 |
| Titanium (Ti) | 0.15 | 0.60 |
| Sulfur (S) | - | 0.015 |
Mechanical Properties
| Property | Typical Value |
|---|---|
| Tensile Strength | 585 - 758 MPa |
| Yield Strength | ≥ 275 MPa |
| Elongation (in 2") | ≥ 30% |
| Hardness (HRB) | 75 - 90 |
| Operating Temperature | Up to 1100°C (2012°F) |
Key Features
- fantastic resistance to oxidation and carburization at high temperatures
excessive strength and longevity at improved temperatures
desirable resistance to aqueous corrosion and strain corrosion cracking
first-rate thermal fatigue resistance
Seamless production ensures better mechanical strength and leak prevention
clean to manufacture, weld, and shape
Equivalent Grades
| ASTM | EN | GOST | JIS | GB |
|---|---|---|---|---|
| ASTM B409 | EN 10216-5 | GOST 5632-72 | JIS NCF 800 | GB/T 17744-2008 |
Application
Inconel 800 seamless tubes and pipes are widely used in:
-
heat exchangers and condensers in electricity plant life
Chemical and petrochemical enterprise gadget
Furnace additives because of oxidation resistance
Nuclear reactors for tubing and pipes
Aerospace and fuel turbine components requiring excessive temperature energy and corrosion resistance
Oil refineries and marine applications requiring corrosion resistance
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
