Alloy Steel Tube Precision Seamless Steel Tubes Cutting Tube

Minimum Order Quantity : 3 TONS Price : Negotiable
Packaging Details : packing in standard seaworthy packages. Delivery Time : 20-45 DAYS
Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram Supply Ability : 50000 TONS PER YEAR
Place of Origin: Zhejiang,China Brand Name: TORICH
Certification: ISO9001,ISO14001,TS16949 Model Number: ASTM A519

Detail Information

Product Name: Alloy Steel Tube Precision Seamless Steel Tubes Cutting Tube Keyword: Alloy Steel Tube Precision Seamless Steel Tubes
Material: 1008,1010,1020,1026,1045,4130,4140, E235, E275, E315, E355, E470 C15, C22, 38Mn6, 41Cr4, 25CrMo4, 30CrMo4, 34CrMo4, 42CrMo4 Shape: Round
Application: For Seamless Circular Tubes Made Of Non-alloy And Alloy Steels For Mechanical And General Engineering Purposes. Delivery Condition: BK,BKW,BKS,GBK,NBK
OD: 5-420mm WT: 0.5-50mm
Length: Max12000mm Brand: TORICH
High Light:

precision steel pipe

,

precision seamless pipe

Product Description

Alloy Steel Tube Precision Seamless Steel Tubes



TORICH is a professional steel tubes supplier from China with over 23 years manufacturing and exporting experience.
Our main products are seamless precision pipe,carbon steel seamless precision pipe,alloy steel seamless precision pipe, stainless steel seamless precision pipe.The material we usually use for producing Alloy Steel Tube Precision Seamless Steel Tubes is10#,20#,1010,1020,1026,ST37,ST44,E235,E215,E355


Standard: ASTM A519, Seamless circular steel tubes for mechanical and general engineering purposes
- Technical delivery conditions Non-alloy and alloy steel tubes

Application: for seamless circular tubes made of non-alloy and alloy steels for mechanical and gneral engineering purposes.

Size range: O.D.: 5-420mm W.T.: 0.5-50mm L:max12000mm

Material:
1008,1010,1020,1026,1045,4130,4140,
E235, E275, E315, E355, E470
C15, C22, 38Mn6, 41Cr4,
25CrMo4, 30CrMo4, 34CrMo4, 42CrMo4



Steel Grade and Chemical Compositions:
Steel Grade C Mn P S Si Cr Mo
max   max max max min
1008 0.10 0.5 0.035 0.035
1010 0.08-0.13 0.30-0.60 0.035 0.035
1018 0.14-0.20 0.30-0.60 0.035 0.035
1020 0.17-0.23 0.30-0.60 0.035 0.035
1026 0.22-0.28 0.60-0.90 0.035 0.035
1035 0.31-0.38 0.60-0.90 0.035 0.035
4130 0.28-0.33 0.40-0.60 0.035 0.035 0.15-0.35 0.80-1.10 0.08-0.25
4140 0.38-0.43 0.75-1.00 0.035 0.035 0.15-0.35 0.80-1.10 0.15-0.25



Steel Grade Yield Ulitmate Elongation RB RB
Strength Strength % min max
  ksi Mpa ksi Mpa
    As-Welded Tubing
1008 30 207 42 290 15 50
1010 32 221 45 310 15 55
1020 38 262 52 359 12 62
1026 45 310 62 427 12 68
1035 50 345 66 455 10 75
4130 55 379 72 496 10 80
4140 70 485 90 621 10 85



Steel Grade Yield Ulitmate Elongation RB RB
Strength Strength % min max
  ksi Mpa ksi Mpa
    Sink-Drawn Tubing
1008 38 262 48 331 8 65
1010 40 276 50 345 8 65
1020 50 345 60 414 8 70
1026 55 379 70 483 7 77
1035 70 483 80 552 7 82
4130 50 345 70 483 20 100
4140 65 448 90 621 20 105



Steel Grade Yield Ulitmate Elongation RB RB
Strength Strength % min max
  ksi Mpa ksi Mpa
    Normalizing Tubing
1008 23 159 38 262 30   65
1010 25 172 40 276 30   65
1020 35 207 50 345 25   75
1026 40 276 60 414 25   80
1035 45 310 65 448 20   85



Steel Grade Yield Ulitmate Elongation RB RB
Strength Strength % min max
  ksi Mpa ksi Mpa
    Mandrel-Drawn Tubing
1008 50 345 60 414 5   73
1010 50 345 60 414 5   73
1020 60 414 70 483 5   80
1026 70 483 80 552 5   85
1035 80 552 90 621 5   90
4130 85 586 95 655 5   90
4140 100 690 110 758 5   90



Steel Grade Yield Ulitmate Elongation RB RB
Strength Strength % min max
  ksi Mpa ksi Mpa
    Mandrel-Drawn Stress-Relieved Tubing
1008 45 310 55 379 12   68
1010 45 310 55 379 12   68
1020 55 379 65 448 10   75
1026 65 448 75 517 10   80
1035 75 517 85 586 10   85
4130 80 552 90 621 10   87
4140 95 655 105 724 10   90



Delivery condition for Alloy Steel Tube Precision Seamless Steel Tubes:
Normalizin rolling process or normalized by heat treatment in a furnance.

Manufacture:
The tubes are manufactured by Seamless Cold Drawn or Seamless Cold Rolling.

Alloy Steel Tube Precision Seamless Steel TubesAlloy Steel Tube Precision Seamless Steel Tubes

Alloy Steel Tube Precision Seamless Steel Tubes Cutting Tube 2Alloy Steel Tube Precision Seamless Steel Tubes Cutting Tube 3Alloy Steel Tube Precision Seamless Steel Tubes Cutting Tube 4Alloy Steel Tube Precision Seamless Steel Tubes Cutting Tube 5
