JIS SCM430 Seamless Mechanical Tubing Plain End For Bicycle Motorcycle Frame

Name: JIS SCM430 Seamless Mechanical Tubing Plain End For Bicycle Motorcycle Frame
Brand: TORICH INTERNATIONAL LIMITED
SKU: ASTM A519
Price: 2,550.00 USD
Availability: InStock

Brand Name:	TORICH
Model Number:	ASTM A519
MOQ:	5 ton
Price:	Negotiable
Payment Terms:	T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability:	6000ton

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

SO9001:2008 ，TS16949

Product Name:

AISI4130 Steel Tubes

Standard:

ASTM A519

Material:

AISI4130/SAE4130

Type:

Seamless

Terms Of Trade:

FOB, CIF, EXW

Brand:

TORICH

Transportation:

Ocean, Air

Certificate:

ISO9001, TS16949

End Protector:

Plain

MTC:

En10204.3.2B

Packaging Details:

In bundles with seaworthy packing

Supply Ability:

6000ton

Highlight:

seamless steel pipe

seamless carbon steel tube

Product Description

TORICH ASTM A519 JIS SCM430 DIN 30GrMo4 SAE4130 Chrome Moli Alloy Round Seamless AISI4130 Steel Tube For Bicycle Motorcycle Frame

1. Grade: JIS SCM430, DIN 30GrMo4, SAE4130/ AISI4130

2. Size: O.D.:6-350mm W.T.:1-35mm L:max12000mm

3. Standard: ASTM A519

4. Certification: ISO9001,TS16949

5. Applications: for Auto industry/for machinery use/Motorcycle frame

6. Chemical Composition and Mechanical Property:

Chemical Composition(%)									Mechanical Property
C	Si	Mn	S	P	Cr	Ni	Cu	Mo	Yield Strength	Tensile Strength
									( σs )	( σb )
0.28~0.33	0.15~0.30	0.40~0.60	≤0.04	≤0.035	≤0.15	0.80~1.10	/	0.15~0.25	≥785(80) (MPa)	≥930(95)
										(MPa)

7. Delivery Conditions

1) BKW (+LC) After last heat treatment there is a light finishing pass (cold drawing)

2) BKS (+SR) After the final cold forming process the tubes are stress relieve annealed.

3) GBK (+A) After the final cold forming process the tubes are annealed in a controlled atmosphere.

4) NBK (+N) After the final cold forming process the tubes are annealed above the upper transformation point in acontrolled atmosphere.

TORICH ASTM A519 JIS SCM430 DIN 30GrMo4 SAE4130 Chrome Moli Alloy Round Seamless AISI4130 Steel Tube For Bicycle Motorcycle Frame
