Name: Automotive Steel Mechanical Tubing Round Shape
Brand: TORICH INTERNATIONAL LIMITED
SKU: ASTM A519 DIN 2391, EN 10305-1, SAE J524, and GB/T 3639
Price: 28,750.50 USD
Availability: InStock

Home > products > Automotive Steel Tubes >

Automotive Steel Mechanical Tubing Round Shape

low carbon steel pipe

steel mechanical tubing

Place of Origin:

Zhejiang,China

Brand Name:

TORICH

Certification:

ISO9001 ISO14001 TS16949

Model Number:

ASTM A519 DIN 2391, EN 10305-1, SAE J524, and GB/T 3639

Request A Quote

Automotive Steel Mechanical Tubing Round Shape

Product Details

Product Name:

ASTM A519 1008 1010 1020 1045 4130 High Quality Automotive Steel Tubes From TORICH

Keyword:

Automotive Steel Tubes

Application:

For Mechinery, Mechanical Engineer

Shape:

Round

Material:

1008 1010 1020 1045 ST52 ST52.3 E355 ST37 16Mn

Delivery Condition:

HR CW SR A N

OD:

5-420mm

WT:

0.5-50mm

Length:

Max 12000mm

Brand:

TORICH

Highlight:

low carbon steel pipe

steel mechanical tubing

Payment & Shipping Terms

Minimum Order Quantity

3 TONS

Price

negotiable

Packaging Details

ASTM A519 1008 1010 1020 1045 4130 High Quality Automotive Steel Tubes from TORICH,packing in standard seaworthy packages

Delivery Time

20-45 DAYS

Payment Terms

T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability

5000 TONS PER MONTH

JIS G3460 Alloy Steel Pipe for low temperature service

Get Best Price

video

Torich Cold Drawn Shock Absorber Tube For Hyduaulic Power System

Get Best Price

video

Cold Drawn Hollow Copper Tube C1100 Air Conditioning Coil Tinned

Get Best Price

video

DIN2391 E235 E355 Cold Drawn Shock Absorber Pipe 10x1 12x1

Get Best Price

86-574-88086983

Contact Now

Product Description

ASTM A519 1008 1010 1020 1045 4130 High Quality Automotive Steel Tubes from TORICH

Products Information:

Size Range:
OD: 4.0-350mm
WT:0.5-50mm
Length: max 12000mm
Thickwall Steel Tube is our strength and regular production montly, mainly for machinery and engineering parts for our customers.

Steel Grade/Steel Material:

Steel Grade and Chemical Compositions:
Steel	C	Mn	P	S	Si	Cr	Mo
Grade	max		max	max	max	min
1008	0.10	0.30-0.50	0.040	0.050
1010	0.08-0.13	0.30-0.60	0.040	0.050
1018	0.15-0.20	0.60-0.90	0.040	0.050
1020	0.18-0.23	0.30-0.60	0.040	0.050
1026	0.22-0.28	0.60-0.90	0.040	0.050
1035	0.32-0.38	0.60-0.90	0.040	0.050
1045	0.43-0.50	0.60-0.90	0.040	0.050
4130	0.28-0.33	0.40-0.60	0.040	0.040	0.15-0.35	0.80-1.10	0.15-0.25
4140	0.38-0.43	0.75-1.00	0.040	0.040	0.15-0.35	0.80-1.10	0.15-0.25

Delivery Condition:

Thermal Treatment:
1) A-Annealed
2) N-Normalized
3) QT-Quenched and Tempered
4) SR-Stress relieved or Finish Anneal

Steel Tube Characteristic:
Good concentricity
Good OD and ID tolerance
High Precision
Stable quality
Smooth Roughness
TORICH QUALITY ASSURANCE

Production Processs:

Seamess Hollow Steel Tube and Cold Drawing or Cold Rolling Production, to achieve the target price by mandrel and die, the more accuracy we can make is higher than technical standard ASTM A519.

Method of Tube Forming:
1. Hot-Finished Mechanical Tubing
2. Cold-Worked Mechanical Tubing
3. Rough -Turned Mechanical Tubing
4. Ground Mechanical Tubing
