STB340 Carbon Steel Heat Exchanger Tubes ASTM A192 ASTM A179 Annealed Surface
Basic Properties
Place of Origin:
CHINA
Brand Name:
TORICH
Certification:
ISO9001, TS16949
Model Number:
ASTM A192/ ASTM A179
Trading Properties
Minimum Order Quantity:
3tons
Price:
USD2500/ton
Payment Terms:
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability:
60000ton/year
Product Summary
TORICH ASTM A192 ASTM A179 STB340 Carbon Seamless Steel Boiler Pipe Applications: for Boilers,Superheaters, Heat-Exchangers, High-pressure Boilers, Steam Boilers Cold Condensers and High-Pressure Services, High-Temperature Services for Boiler Constructions Manufacture: Tubes are manufactured by ...
Product Details
Highlight:
carbon steel tube
,heat exchanger tubes
Product Name:
Seamless Steel Boiler Pipe
Standard:
ASTM A192/ ASTM A179
Technique:
Seamless
Section Shape:
Round
Certification:
ISO9001, TS16949
Alloy Or Not:
No
Secondary Or Not:
Non-secondary
Special Tube:
Boiler Tube
Surface:
Annealed
Shipment:
Ocean/ Air
Product Description
TORICH ASTM A192 ASTM A179 STB340 Carbon Seamless Steel Boiler Pipe
Applications:
for Boilers,Superheaters,
Heat-Exchangers,
High-pressure Boilers,
Steam Boilers
Cold Condensers and High-Pressure Services,
High-Temperature Services for Boiler Constructions
Manufacture: Tubes are manufactured by seamless process and both hot finished and cold finished are applicable.
High pressure a192 a179 seamless carbon boiler tube for sale
a192 a179 seamless boiler tube
Heat treatment:Hot finished tubes need not be heat treated.Cold Finished tubes are heat treated after the final cold finishing pass at a temperature of 1200℉(650℃) or higher
Steel grade SA192 Chemical Composition & Mechanical properties
| C | Mn | P | S | Si | Tensile Strength | Yeild point | Elongation |
| 0.06-0.18 | 0.27-0.63 | 0.035Max | 0.035Max | 0.25Max | min ksi[Mpa] 47[325] | min ksi[Mpa] 26[180] | ≥35% |
Hardness
| Brinell Hardness | Rockwell Hardness Number |
| WT≥0.200in(5.1mm) | WT<0.200in(5.1mm) |
| 137HRB | 77HRB |
Packing: Boiler pipe packed in bundles, in wooven bags.
