Heat Exchanger Round Ss Seamless Pipe / Industrial Stainless Steel Boiler Tubes
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
ISO 9001 ISO14001 TS16949
Model Number:
ASTM A213
Trading Properties
Minimum Order Quantity:
5 tons
Price:
negotiable
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
60000 Ton per Year
Product Summary
TORICH SS304 SUS304 316 316L Stb340 13CrMo44 Heat Exchanger Fin Pipe Round Industrial Seamless Stainless Steel Boiler Tube OD:6-127mm WT:0.5-12mm Grade: 304 316 317 etc Seamless stainless Steel pipe coil Coiled heat exchanger Tube SUS304 / 304L / 316L Mechanical Properties: Material Mechanical ...
Product Details
Highlight:
stainless steel round tube
,large diameter stainless steel tube
Characteristic:
Stainless Boiler Tube
Material:
SS304 SUS304 316 316L Etc
Production Method:
Cold Drawn
Package:
In Bundles Or As Per Requests
End Protector:
Plain / Beveled
Length:
1-12m
Type:
Stainless Boiler Tube
MTC:
EN10204.3.1
Product Description
TORICH SS304 SUS304 316 316L Stb340 13CrMo44 Heat Exchanger Fin Pipe Round Industrial Seamless Stainless Steel Boiler Tube
OD:6-127mm
WT:0.5-12mm
Grade: 304 316 317 etc
Seamless stainless Steel pipe coil Coiled heat exchanger Tube SUS304 / 304L / 316L
Mechanical Properties:
| Material | Mechanical Properties | ||
| Tensile Strength ≥ MPa | yield strength ≥ MPa | Elongation ≥ % | |
| T12 | 415 | 220 | 30 |
| TP304 | 515 | 205 | 35 |
| TP304L | 458 | 170 | 35 |
| TP316 | 515 | 205 | 35 |
| TP316L | 485 | 170 | 35 |
| TP317 | 515 | 205 | 35 |
| TP317L | 515 | 205 | 35 |
| TP321 | 515 | 205 | 35 |
Acknowledge:
Gauge-Inch-mm Gauge 12 14 15 16
Production Steel Tube:
Eddy Current Test and Ultrasonic Test:
Packing:
