Ferritic And Martensitic Stainless Steel Tube TP410 TP430 6-219.1mm O.D
Product Details
stainless steel round tube
,stainless tube steel
Ferritic and Martensitic TP410 TP430 Stainless Steel Tube for Construction and Decoration
Stainless Steel is the generic name given to group of corrosion and heat resisting Steels. These are iron-base alloys containing chromium as the main alloying element with a minimum of 10.5% to make it resistant to staining, rusting scaling in most of the corrosive environment.
The complete range of Stainless Steel can be classified into 3 major categories viz. Austenitic , Ferritic and Martensitic.
Austenitic : -
This Category of Stainless Steel contains 16 to 26% Chromium and 6 to 22% Nickel. They are non- magnetic and have excellent corrosion resistance. They are not hardenable by heat treatment. However, they can develop high strength on cold working. They are identified in the AISI 300 series.
Ferritic :
This category contains 12 to 30% Chromium without any Nickel. They are ferro-magnetic in nature and generally not hardenable by heat treatment. They are identified in AISI 400 series.
Martensitic : -
This Category contains 11 to 14% Chromium without any Nickel. They are ferro-magnetic in nature and are hardenable by heat treatment. They are also identified in the AISI 400 Series.
|
Grade
| UNS | Chemical ,% | |||||||
| C max | Mnmax | P max | S max | Si max | Ni | Cr max | Mo max | ||
| TP410 | S4100 | 0.15 | 1.00 | 0.040 | 0.030 | 1.0 | … | 11.5-13.5 | … |
| S42035 | 0.08 | 1.00 | 0.045 | 0.030 | 1.0 | 1.0-2.5 | 13.5-15.5 | … | |
| TP430 | S43000 | 0.12 | 1.00 | 0.040 | 0.030 | 1.0 | … | 16.0-18.0 | … |
| TP446-1 | S44600 | 0.025 | 1.50 | 0.040 | 0.030 | 1.0 | ≤0.75 | 23.0-27.0 | … |
| TP446-2 | S44600 | 0.012 | 1.50 | 0.040 | 0.030 | 1.0 | ≤0.50 | 23.0-27.0 | … |
| 26-3-3 | S44660 | 0.030 | 1.00 | 0.040 | 0.030 | 1.0 | 1.0-3.5 | 25.0-28.0 | 3.0-4.0 |
| Grade | UNS |
Tensile Strength Min Ksi(Mpa)
| Yield Strength Min Ksi(Mpa) | Elongation in 2 in or 50 mm ,Min,% | Rockwell Hardness Max |
|
TP410
| S4100 | 60(415) | 30(205) | 20 | 95 |
|
S42035
| 80(550) | 55(380) | 16 | 88 | |
|
TP430
| S43000 | 60(415) | 35(240) | 20 | 90 |
|
TP446-1
| S44600 | 70(485) | 40(275) | 18 | 95 |
|
TP446-2
| S44600 | 60(415) | 40(275) | 20 | 95 |
|
26-3-3
| S44600 | 85(585) | 65(450) | 20 | 25 |
Available Size:
OD: 6-219.1mm
WT:0.2-12.7mm
L: 20 Meter Max
Available Specification:
ASTM A268/A268M ASME SA268/SA268M
Delivery Condition:
- Annealed and Pickled
- Bright and Annealed
- Annealed and Pickled + Polished
-
