ASTM A511 TP316 304 Thick Wall Seamless Stainless Steel Pipe For Mechanical
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
Minimum Order Quantity : | 5Tons | Price : | negotiable |
---|---|---|---|
Packaging Details : | Stainless Steel Pipes are packed in wooden boxes in seaworthy packing. | Delivery Time : | 30-45 work days |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 5000Tons per Year |
Place of Origin: | ZHEJIANG, CHINA | Brand Name: | TORICH |
---|---|---|---|
Certification: | ISO9001, ISO14001, TS16949 | Model Number: | GB/T14976-2012 |
Detail Information |
|||
Keyword: | Stainless Steel Pipe | Material: | 12Cr18Ni9, 06Cr19Ni10, 022Cr19Ni10 Etc |
---|---|---|---|
WT: | 0.5-50mm | OD: | 20-300mm |
Length: | 1-12m | Surface: | Polished, Brightly, Anneled |
Technique: | Hot Rolled (W-H), Cold Drawn (W-C) | Usage: | For Fluid Transport |
High Light: | stainless tube steel,large diameter stainless steel tube |
Product Description
Standard
|
GB/T14976-2012 Seamless Stainless Steel Pipe for Fluid Transport
|
Matrial
|
12Cr18Ni9, 06Cr19Ni10, 022Cr19Ni10, 06Cr19Ni9NbN, 022Cr19Ni10N etc
|
Size
|
WT: 0.5mm-50mm OD: 20-300mm Length: as customers' requirement
|
Technique
|
Hot Rolled (W-H), Cold Drawn (W-C)
|
Surface Treament
|
Annealed, Brightly Annealed, Polish
|
Test
|
Tension Test, Flaring Test, Flange Test,
Reverse Test, Hardness Test,
Hydrostatic or Nondestructive Electric Test etc
|
Chemical Composition
Steel Grade
|
C
max
|
Si
max
|
Mn
max
|
P
max
|
S
max
|
Ni
|
Cr
|
N
|
|
S30210
|
12Cr18Ni9
|
0.15
|
1.00
|
2.00
|
0.035
|
0.030
|
8.00-10.00
|
17.00-19.00
|
0.10
|
S30408
|
06Cr19Ni10
|
0.08
|
1.00
|
2.00
|
0.035
|
0.030
|
8.00-11.00
|
18.00-20.00
|
-
|
S30403
|
022Cr19Ni10
|
0.03
|
1.00
|
2.00
|
0.035
|
0.030
|
8.00-12.00
|
18.00-20.00
|
-
|
S30458
|
06Cr19Ni10N
|
0.08
|
1.00
|
2.00
|
0.035
|
0.030
|
8.00-11.00
|
18.00-20.00
|
0.1-0.16
|
S30453
|
022Cr19Ni10N
|
0.03
|
1.00
|
2.00
|
0.035
|
0.030
|
8.00-11.00
|
18.00-20.00
|
0.1-0.16
|
S30908
|
06Cr23Ni13
|
0.08
|
1.00
|
2.00
|
0.035
|
0.030
|
12.00-15.00
|
22.00-24.00
|
-
|
S31008
|
06Cr25Ni20
|
0.08
|
1.00
|
2.00
|
0.035
|
0.030
|
19.00-22.00
|
24.00-26.00
|
-
|
Mechanical Properties
Steel Grade
|
Rm MPa, min
|
Rp MPa, min
|
A %, min
|
12Cr18Ni9
|
520
|
205
|
35
|
06Cr19Ni10
|
520
|
205
|
35
|
022Cr19Ni10
|
480
|
175
|
35
|
06Cr19Ni10N
|
550
|
275
|
35
|
0022Cr19Ni10N
|
685
|
245
|
40
|
06Cr23Ni13
|
520
|
205
|
40
|
06Cr25Ni20
|
520
|
205
|
40
|
QUALITY CONTROL:
1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking
100% of our steel tubes are dimensionally checked
100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.
100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects.
PACKING:
Each tube in a plastic bag, then put tubes in a seaworthy woven bag ,each unit weight 400kg-500kg/bundle.
With strong wood structure box packing by containers loading and shipping.
Or as customer's requirement.
20 ft container - GP: 5.8m (Length) * 2.13m (Width) * 2.18m (Hight) ------ Max Gross Weight: 25MT/container.
40 ft container - GP: 11.8m (Length) * 2.13m (Width) * 2.18m (Hight) ------ Max Gross Weight: 27MT/container.
40 ft container - HG: 11.8m (Length) * 2.13m (Width) * 2.72m (Hight) ------ Max Gross Weight: 27MT/container.
Port Shanghai
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples of carbon seamless steel tube ? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
