ASTM A511 TP316 304 Thick Wall Seamless Stainless Steel Pipe For Mechanical
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
| Minimum Order Quantity : | 1 Tons | Price : | negotiable |
|---|---|---|---|
| Packaging Details : | Standard seaworthy export packing other types of packing, can be customized as every requirement. | Delivery Time : | 3-6 Weeks |
| Payment Terms : | L/C, D/A, D/P, Western Union, T/T, MoneyGram | Supply Ability : | 5000 Tons per month |
| Place of Origin: | Zhejiang China | Brand Name: | TORICH |
|---|---|---|---|
| Certification: | ISO | Model Number: | ASTM |
|
Detail Information |
|||
| Standard: | AISI, ASTM, DIN, EN, GB, JIS | Type: | Welded |
|---|---|---|---|
| Steel Grade: | 300 Series | Outer Diameter: | 10~250mm |
| Thickness: | 0.4-30mm | Surface: | BA/2B/NO.1/NO.3/NO.4 |
| Technique: | Cold Rolled Hot Rolled | Length: | 3000mm~6000mm |
| High Light: | stainless steel round tube,large diameter stainless steel tube |
||
Product Description
Stainless steel does not readily corrode, rust or stain with water as ordinary steel does, but despite the name it is not fully stain-proof, most notably under low oxygen, high salinity, or poor circulation environments. There are different grades and surface finishes of stainless steel to suit the environment the alloy must endure. Stainless steel is used where both the properties of steel and resistance to corrosion are required.
| aterial: | SS201(Ni 0.8%-1.2%) | Standard: | US ASTM A554 |
| SS301(Ni 6.0%-7.0%) | Surface | Satin:180G/240G/320G/400G | |
| SS304(Ni 8.0%-12.0%) | Mirror:600G/800G | ||
| SS316(Ni 10.0%-14.0%) | Outdiameter: | 9.5mm~101.6mm | |
| SS316L(Ni 12.0%-15.0%) | Thickness: | 0.4mm~2.0mm | |
| Tolerance | a)Out diameter:± 0.2mm | Length: |
5.8M/6.0M/6.1M(or customer's requirement) |
| b)Thickness is ±0.03mm | Application range |
construction,decoration,industry, kitchen,medical equipment |
|
| c)Length:±10mm | Package | Regualr export package with PP bag | |
| d)Weight:±15% | Delivery time | 15-20days |
| Material Composition | 201 | 202 | 304 | 316 | 430 | |
|
Chemical Composition of Material |
C | ≤0.15 | ≤0.15 | ≤0.08 | ≤0.08 | ≤0.12 |
| Si | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | |
| Mn | 5.5-7.5 | 7.5-10 | ≤2.00 | ≤2.00 | ≤1.00 | |
| P | ≤0.06 | ≤0.06 | ≤0.045 | ≤0.045 | ≤0.040 | |
| S | ≤0.03 | ≤0.03 | ≤0.030 | ≤0.030 | ≤0.030 | |
| Cr | 16-18 | 17-19 | 18-20 | 16-18 | 16-18 | |
| N | 3.5-5.5 | 43196 | 8-10.5 | 43387 | ||
| Mo | 2.0-3.0 | |||||
| Mechanical Property | Material Item | 201 | 202 | 304 | 316 | |
| Tensile Strength | ≥535 | ≥520 | ≥520 | ≥520 | ||
| Yield Strength | ≥245 | ≥205 | ≥205 | ≥205 | ||
| Extension | ≥30% | ≥30% | ≥35% | ≥35% | ||
| Hardness (HV) | <253 | <253 | <200 | <200 | ||
1.100% Raw material;
2.We offer competitive price with best service;
3.We can provide stainless steel processing services;
4.We have win high reputation based on best quality products;
5.Stainless steel tube are widely used in petroleum, chemical, medical, food,
light industry, machinery, instruments and other industrial pipes and mechanical parts etc.
