ASTM A789 Super Duplex 2507 Pipe Cold Drawn Stainless Steel Tube For Petrochemical
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
| Minimum Order Quantity : | 2 Tons | Price : | negotiable |
|---|---|---|---|
| Packaging Details : | Each piece in polybag and several pieces per bundle | Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 500 Tons per month |
| Place of Origin: | Zhejiang China | Brand Name: | Torich |
|---|---|---|---|
| Certification: | ISO 9001 | Model Number: | ASTM A249 |
|
Detail Information |
|||
| Delivery Time: | 5-12 Days | Outer Diameter: | Φ630mm-Φ3000mm |
|---|---|---|---|
| Thickness: | 3mm-30mm | Length: | According To Your Requirements |
| Production Technology: | Hot Rolled | MOQ: | 1 Tons |
| High Light: | stainless steel round tube,large diameter stainless steel tube |
||
Product Description
ASTM A249 3000mm Large Diameter Stainless Steel Pipe
| Name | large diameter steel pipe |
| Standard | ASTM, GB, JIS, DIN, EN, AISI, ISO |
| Material Grade | TP304 TP304L TP316 TP316L TP347 TP347H TP321 TP321H TP310 TP310S |
| TP410 TP410S TP403 | |
| S31803/S32205 S32750 S32760 | |
| Outer Diameter |
Welded Pipe: single slit(Φ8mm-Φ630mm);
Girth(Φ630mm-Φ3000mm), |
| Thickness |
Welded Pipe: single slit(0.5mm-25mm);
Girth(3mm-30mm) |
| Length | Commonly 5.8 Meters or 6.0 Meters, or as customers' request |
| Tolerance | According to the Standard, +/-10% Commonly. |
| Surface | 180#, 320#, 400# Satin / Hairline, Bright Anneal, Pickle, 400#, 500#, 600# or 800# Mirror finish |
| Application | Petrochemical industry, chemical fertilizer industry, oil refining industry, oil and gas industry, light industry and food industry, pulp and paper industry, energy and environmental industries. |
| Test |
Flaring test, Flattening test, Bending Test, Hydraulic Test, Eddy Current test |
Tests:
Flattening test
Flaring test
Reverse Flattening test
Expansion test
Tensile test
Elongation test
Pressure test
According to above tests to check the quality of steel pipes and its performance.
Quality Check pionts:
Straight
Smooth ends from burrs
Free from scale
Injurious defect
A workmanlike finish
Tolerances specified for diameter and wall thickness.
Packaging Details
1. Each piece in polybag and several pieces per bundle
2. Accoding to your requestments
3. The inner size of container is below:
20ft GP: 5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP: 12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC: 12032mm(Length)x2352mm(Width)x2698mm(High)
How to get the sample?
1.You are requested to pay for sample charges and courier charges from China to your country; and the free sample is according the product like size, steel grade and quantity, please consult our sales for details
2.Sample charges will be refunded when order is placed.
What is your Payment Term?
1.T/T: 30% deposit in advance, the balance 70% paid before shipment
2.30% down payment, the balance 70% paid against L/C at sight
3.Upon negotiation
Who are your customers?
Stockists, Distributors,Wholesalors,Agents, Traders, End Users, etc
How long will you react on our requirement?
Your requirement would be treated within 24 hours on weekdays. Quotations would be sent upon technical details confirmed by customer!
Any more questions about your doubts, please feel free to send us your emails or call!
