DIN 2393 St37-2 Welded Steel Tube Precision Cold Drawn Welded Steel Pipe For Sleeve
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
Minimum Order Quantity : | 5Tons | Price : | USD500-1000/Ton |
---|---|---|---|
Packaging Details : | Tubes are packed in wooden boxes or hexagonal bundles in seaworthy packing. | Delivery Time : | 30-45 work days |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 2000Tons per Year |
Place of Origin: | ZHEJIANG, CHINA | Brand Name: | TORICH |
---|---|---|---|
Certification: | ISO9001, ISO14001, TS16949 | Model Number: | GB/T3091 |
Detail Information |
|||
Keyword: | Welded Steel Tubes | Standard: | GB/T3091 |
---|---|---|---|
Material: | Q195 Q215A Q215B Q235A Etc | OD: | 10 - 219.1 Mm |
WT: | 2 - 4 Mm | Length: | 3000-1200 Mm |
Surface: | Oiled | Technique: | ERW, ERW /SSAW /LSAW |
High Light: | welded steel pipe,electric resistance welded steel tube |
Product Description
Harnessing the modern technology and latest machines, we have cemented our status as a prime figure in the industry. As a Manufacturer, Exporter and Supplier of Mechanical Welded Seamless Steel Tubes, we offer sturdiness, durability and dependability thanks to the fact that we strictly use first-rate materials sourced from trusted vendors. Mechanical Welded Seamless Steel Tubes are available at reasonable rates.
Standard
|
GB/T3091
|
Matrial
|
Q195 Q215A Q215B Q235A Q235B Q295A Q295B Q345A Q345B
|
Size
|
OD: 10-219.1mm WT: 2-4mm Length: 3-12m
|
Manufacturing process
|
ERW /SSAW /LSAW
|
Application
|
For Water,Air,Steam,Gas,Low Pressure Liquid Delivery
|
OD
|
Permissible Variation in OD
|
Permissible Variation in WT
|
|
Pipe
|
Pipe end (within 100mm)
|
||
D≤48.3
|
±0.5
|
-
|
±10% t
|
48.3
|
±1% D
|
-
|
|
273.1
|
±0.75% D
|
+2.4
-0.8
|
|
D>508
|
±1% or ± 10.0
(choose smaller one)
|
+3.2
-0.8
|
Mechanical Properties
Grade
|
Lower Yeild Strength/MPa, min
|
Tensile Strength/MPa, min
|
Elongation %, min
|
||
t≤16mm
|
t>16mm
|
D≤168.3mm
|
D>168.3mm
|
||
Q195
|
195
|
185
|
315
|
20
|
89
|
Q215A, Q215B
|
215
|
205
|
335
|
||
Q235A, Q235B
|
235
|
225
|
370
|
||
Q275A, Q275B
|
275
|
265
|
410
|
13
|
18
|
Q345A, Q345B
|
345
|
325
|
470
|
1.Pipes will be delivered by welded.
2.According to the requirements of customers, after consultation between supplier and customer, the pipe can be delivered by heat - treatedweld, or by heat treatment.
3.According to the requirements of customers, after consultation between supplier and customer, the pipe which OD≤308mm can be delivered by hot galvanized, or other protective coating.
Size Measurement
NDT inspection: by eddy current test ultrasonic test
Mechanical test.
QUALITY CONTROL:
1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking
100% of our steel tubes are dimensionally checked
100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.
100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects.
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples of carbon seamless steel tube ? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
TORICH GB/T3091 ERW SSAW LSAW Welded Carbon Steel Tube for Low Pressure Liquid Delivery
