Aisi8620 Cold Drawn Alloy Steel Seamless Tube For Steam Turbine - Gear Unit
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
ISO 9001 ISO14001 TS16949
Model Number:
AISI8620
Trading Properties
Minimum Order Quantity:
5 tons
Price:
negotiable
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
60000 Ton per Year
Product Summary
Products Description: for Steam Turbine-Gear Unit Cold Drawn Seamless Alloy Steel Tubes AISI8620 Quick Detail: Chemical Compositions: Steel Grade C Si Mn Cr Ni Mo P S Ti 20CrNiMo 0.17-0.23 0.17-0.37 0.60-0.95 0.40-0.70 0.35-0.75 0.20-0.30 ≤0.035 ≤0.035 - AISI8620 0.18-0.23 0.15-0.35 0.70-0.90 0.40-0...
Product Details
Highlight:
alloy steel tube
,alloy steel seamless tube
Characteristic:
Alloy Steel Tube AISI8620
Material:
AISI8620, 20CrNiMo Etc
Production Method:
Seamless Cold Drawn
Package:
In Bundles Or As Per Requests
End Protector:
Plain / Beveled
Length:
2-12m
Type:
Alloy Steel Tube
MTC:
EN10204.3.1
Product Description
Products Description:
for Steam Turbine-Gear Unit Cold Drawn Seamless Alloy Steel Tubes AISI8620
Quick Detail:
Chemical Compositions:
| Steel Grade | C | Si | Mn | Cr | Ni | Mo | P | S | Ti |
| 20CrNiMo | 0.17-0.23 | 0.17-0.37 | 0.60-0.95 | 0.40-0.70 | 0.35-0.75 | 0.20-0.30 | ≤0.035 | ≤0.035 | - |
| AISI8620 | 0.18-0.23 | 0.15-0.35 | 0.70-0.90 | 0.40-0.60 | 0.40-0.70 | 0.15-0.25 | ≤0.035 | ≤0.040 | - |
| AISI8620H | 0.17-0.23 | 0.15-0.35 | 0.60-0.95 | 0.35-0.65 | 0.35-0.75 | 0.15-0.25 | - | - | - |
| 20CrMnTiH | 0.17-0.23 | 0.17-0.37 | 0.80-1.15 | 1.00-1.35 | - | - | ≤0.035 | ≤.035 | 0.04-0.10 |
Mechanical Property:
| Steel Grade | Yield Strength MPa | Tensile Strength MPa | Elongation % |
| 20CrNiMo | 785 | 980 | 9 |
| AISI8620 | |||
| AISI8620H | |||
| 20CrMnTiH | 835 | 1080 | 10 |
Applications: for Steam Turbine-Gear Unit
Introduction:
Alloy steels contain a wide range of steels whose compositions exceed the limitations of C, Mo, Cr, Va, Mn, Ni, Si, and B fixed for carbon steels. These steels are more responsive to mechanical and heat treatments than carbon steels.
AISI 8620 alloy steel is a common, carburizing alloy steel. This alloy steel is flexible during hardening treatments, thus enabling improvement of case/core properties. The following datasheet will provide more details about AISI 8620 alloy steel.
Production Steel Tube:
Eddy Current Test and Ultrasonic Test:
Packing:
