Nickel Alloy Steel Pipe Od 13.7 - 168.3mm High Precision For Steam Trubine
Product Details
alloy steel tube
,seamless alloy steel pipe
TORICH ASTM B444 UNS N06625 UNS N06852 UNS N06219 Nickel Alloy Pipe and Tube
Standard: ASTM B444, ASTM B829
Size Range: OD: 13.7 - 168.3 mm, WT: 1.6 - 8.6mm, Length: 0.3-6m
Steel Grade: UNS N06625, UNS N06852, UNS N06219
Reference Documents: B829 Specification for General Requirements for Nickel and Nickel Alloy Seamless Pipe and Tube
Condition:
-----UNS N06625 products are furnished in two grades of different heat-treated conditions:
Grade1(annealed)--Material is normally employed in service temperatures up to 1100°F(593℃).
Grade2(solution annealed)--Material is normally employed in service temperatures above 1100°F(593℃) when resistance to creep and rupture is required.
-----Alloy UNS N06219 and UNS N06852 are supplied in the solution annealed condition only.
Chemical Requirements:
| Element | Composition Limits,% | ||
| N06852 | N06625 | N06219 | |
| C | 0.05max | 0.10max | 0.05max |
| Mn | 0.50max | 0.50max | 0.50max |
| Si | 0.50max | 0.50max | 0.70-1.10 |
| P | 0.015max | 0.015max | 0.020max |
| S | 0.015max | 0.015max | 0.010max |
| Cr | 20.0-23.0 | 20.0min | 18.0-22.0 |
| Nb+Ta | ... | 23.0max | ... |
| ... | 3.15min | ... | |
| ... | 4.15min | ... | |
| Nb | 0.51-1.00 | ... | ... |
| Co(if determined) | ... | 1.0max | 1.0max |
| Mo | 8.0-10.0 | 8.0min | 7.0-9.0 |
| 10.0max | ... | ||
| Fe | 15.0-20.0 | 5.0max | 2.0-4.0 |
| Al | 0.40max | 0.40max | 0.50max |
| Ti | 0.40max | 0.40max | 0.50max |
| Cu | ... | ... | 0.50max |
| Nickel | Bal | 58.0min | Bal |
Referenced ASTM Standard:
E829 Specification for general requirements for Nickel and Nickel alloy seamless pipe and tube.
E112 Test Methods for determining the average grain size.
G28 Test methods for detecting susceptibility to intergranular corrosion in wrought, Nickel-Rich, Chromium-Bearing Alloys.
G48 Test methods for piting and crevice corrosion resistance of stainless steel and related alloys by use of ferric chloride solution.
Keywords: Seamless pipe; seamless tube; N06219; N06625
Packing:
Torich's Chemical assurance
1.Each lot of raw materials will be tested by spectrometer before put in storage.
2.100%PMI the mother pipe to ensure we put right material.
2.100%PMI the finished pipe again to ensure we produced right grade
FAQ
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, and it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but you need to pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance , balance before shippment.
If you have another question, pls feel free to contact us
