Notch Toughness Welded Steel Tube Astm A333 For Low Temperature Service
Product Details
welding steel tubing
,electric resistance welded steel tube
competitive Advantage:
100% good quality and price
The best service in steel field.. Including after-sales service
Reasonable price. We only illing to do business with sincere buyers.
We could produce this pipe according American standard.
We are also a manufacturer,so we can provide the products in conformity with your requirements
rapidly Our company has rich technical force and advanced production equipment and coordinated
advanced test equipment and method.Name: ASTM A214 Electric-Resistance-Welded Carbon Steel Heat-exchanger and Condenser Tubes
Brand: TORICH
Material: Electric-Resistance Welded Pipes
O.D: 0-76.2mm
W.T: 0.4-3.2mm
Payment : L/C, D/A, D/P, T/T, Western Union, MoneyGram
Surface Condition: Be free of scale
Packing : Oil protection in bundles or in carton boxes or wooden boxes
Applications: Heat-exchangers , Condensers
Heat Treatment
After welding , all tubes shall be heat treated at a temperature of 1650ºF (900ºC) or higher and followed by cooling in air or in the cooling chamber of a controlled atmosphere furnace.
Chemical Composition
Carbon , max% 0.18
Manganese, % 0.27-0.63
Phosphorus max% 0.035
Sulfur, max% 0.035
Hardness Requirement
The tubes shall have a hardness number not exceeding 72 HRB
Mechanical Tests Required
1.Flattening Test
2.Flange Test
3.Reverse Test
4.Hardness Test
5.Hydrostatic or Nondestructive Electric Test
Standard: ASTM A333, ASTM A370, ASTM A999/A999M, ASTM A671, E23, E165, E709
Size range: OD: 4-420mm
WT: 0.5-50mm
Length: 1-12m
Material: Q195, Q215, Q235, Q345, Gr1,Gr3,Gr4,Gr6,Gr7,Gr8,Gr9,Gr10,Gr11
Test: Transverse or Longfitudinal Tensile Test and Flattening Test
Impact Test
Chemical Requirements
| Element | Grade1 | Grade3 | Grade4 | Grade6 | Grade7 | Grade8 | Grade9 | Grade10 | Grade11 |
| C, max | 0.30 | 0.19 | 0.12 | 0.30 | 0.19 | 0.13 | 0.20 | 0.20 | 0.10 |
| Mn | 0.40-1.06 | 0.31-0.64 | 0.50-1.05 | 0.29-1.06 | 0.90 max | 0.90 max | 0.40-1.06 | 1.15-1.50 | 0.6 max |
| P, max | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.035 | 0.025 |
| S, max | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.015 | 0.025 |
| Si | -- | 0.18-0.37 | 0.08-0.37 | 0.10min | 0.13-0.32 | 0.13-0.32 | -- | 0.10-0.35 | 0.35max |
| Ni | -- | 3.18-3.82 | 0.47-0.98 | 0.40max | 2.03-2.57 | 8.40-9.60 | 1.60-2.24 | 0.25max | 35.0-37.0 |
| Cr | -- | -- | 0.44-1.01 | 0.30max | -- | -- | -- | 0.15max | 0.50max |
| Cu | -- | -- | 0.40-0.75 | 0.40max | -- | -- | 0.75-1.25 | 0.15max | -- |
| Al | -- | -- | 0.04-0.30 | -- | -- | -- | -- | 0.06max | -- |
| V | -- | -- | -- | 0.08 | -- | -- | -- | 0.12 | -- |
| Nb, max | -- | -- | -- | 0.02 | -- | -- | -- | 0.05 | -- |
| Mo, max | -- | -- | -- | 0.12 | -- | -- | -- | 0.05 | 0.50max |
| Co | -- | -- | -- | -- | -- | -- | -- | -- | 0.50max |
Characteristic:
Good concentricity High Precision
Good surface quality Stable quality
Good OD and ID tolerance Smooth Roughness
competitive Advantage:
100% good quality and price
The best service in steel field.. Including after-sales service
Reasonable price. We only illing to do business with sincere buyers.
We could produce this pipe according American standard.
We are also a manufacturer,so we can provide the products in conformity with your requirements
rapidly Our company has rich technical force and advanced production equipment and coordinated
advanced test equipment and method.
-
Auto Parts ASTM A513 Cold Rolling Welded Steel Tubes with DOM Production
Auto Parts ASTM A513 Welded Steel Tubes with DOM production ASTM A513 Electric-Resistance-Welded Carbon and Alloy Steel Mechanical Tubing Applications: for Machinery, Mechanical Engineering 1. Standard: ASTM A513 cold rolling welded precision steel tubes 2. Steel Grade: SAE1010, SAE1020, other materials upon agreement with customers. 3. Production method: Cold rolling on the weled steel tubes, to reach high accuracy on the OD and WT tolerance 4. Size range: O.D.:6-350mm W.T. -
25mm Diameter Bright Annealing Seamless Steel Tube for Hydraulic Systems
EN10305-1 E235 E355 NBK Bright Annealing Precision Steel Pipes for Hydraulic Systems EN10305-1 NBK Bright Annealed Precision steel pipes for Hydraulic system OD:4-80 (mm) WT0.5-10 (mm) Length 1000-12000mm Product name: Seamless Precision Steel Pipe Application: for hydraulic systems precision steel pipes for Hydraulic system OD (mm) WT (mm) Length (mm) 4 0.5 5800-6000 4.0 1.0 5800-6000 5.0 1.0 5800-6000 6.0 1.0 5800-6000 6.0 1.5 5800-6000 8.0 1.0 5800-6000 9.5 0.89 5800-6000 -
Precision Seamless Black Phosphating Steel Tube for Hydraulic Systems
Steel Pipes with high precision for Hydraulic Systems with Black Phosphating surface Black Phosphated Hydraulic Tubes with High Precision and tight tolerance, the tubes are produced by precision cold drawn and cold rolling, then bright annealed in a protected atmosphere, afterwards it is blackphosphated on the surface Production process: DIN series tubes, cold drawn and bright annealed precision seamless steel tube is used as the tube to be phosphated. The phosphorization is -
Precision Seamless Galvanized Steel Tubes DIN2391 EN103052 ST35.0 ST37
Precision Seamless Galvanized Steel Tubes DIN2391 EN103052 ST35.0 ST37 Production Process: Cold rolling by Cold pilger machine and Cold rolling machine,galvanized and zinc plated could be applied. Cold Rolled and Galvanized Steel Tube Production process: DIN highly accurate, cold rolled and bright seamless steel tube is used as the tube to be galvanized. The outer wall of tube is electroplated. The caps are covered at two ends of tube to prevent from the dust. Main Features:
