Round Shape Seamless Steel Tube for Oil Pipeline API5CT-0735 J55 K55 N80
Product Details
seamless steel pipe
,seamless carbon steel tube
TORICH API5CT-0735 J55, K55, N80 Oil Tube and Casing
TORICH API5CT-0735 J55, K55, N80 Oil Tube and Casing
Standard: API 5CT,API 5L,ASTM A106,ASTM A53
Size range: OD: 50-508mm
WT: 2-20mm
Length: 15m max
Material: J55, K55, N80, N80Q,L80,P110 etc
Usage: Oil Pipeline
Casing list
| Code | OD | KG/M | WT | End Machining Form | |||||||||
| 1 | 2 | H40 | J55 K55 | M65 | L80 R95 | N80 1,Q | C90 T95 | C110 | P110 | Q125 | |||
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 |
| 4-1/2 | 9.50 | 114.30 | 14.14 | 5.21 | PS | PS | PS | - | - | - | - | - | - |
| 4-1/2 | 10.50 | 114.30 | 15.63 | 5.69 | - | PSB | PSB | - | - | - | - | - | - |
| 4-1/2 | 11.60 | 114.30 | 17.26 | 6.35 | - | PSLB | PLB | PLB | PLB | PLB | P | PLB | - |
| 4-1/2 | 13.50 | 114.30 | 20.09 | 7.73 | - | - | PLB | PLB | PLB | PLB | P | PLB | |
| 4-1/2 | 15.10 | 114.30 | 22.47 | 8.56 | - | - | - | - | - | - | - | PLB | PLB |
| 5 | 11.50 | 127.00 | 17.11 | 5.59 | - | PS | PS | - | - | - | - | - | - |
| 5 | 13.00 | 127.00 | 19.35 | 6.43 | - | PSLB | PSLB | - | - | - | - | - | - |
| ... | |||||||||||||
| 20 | 133.00 | 508.00 | 197.93 | 16.13 | - | PSLB | - | - | - | - | - | - | - |
Workshop:
Testing Equipments:
HW200B CS Analyzer Cryostat For Impact Test
Pendulum Impact Tester 300KN Electronic Universal Tester
Characteristic:
Good concentricity High Precision
Good surface quality Stable quality
Good OD and ID tolerance Smooth Roughness
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, and it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but you need to pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance , balance before shippment.
If you have another question, pls feel free to contact us
