TORICH GB/T3093 Q345 High Pressure Steel Tubes For Diesel Engine
Basic Properties
Place of Origin:
China
Brand Name:
TORICH
Certification:
ISO 9001,ISO 14001,TS 16949
Model Number:
GB/T 3093
Trading Properties
Minimum Order Quantity:
5
Price:
negotiable
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
50000tons/year
Product Summary
TORICH GB/T3093 Q345 High-Pressure Seamless Steel Tubes For Diesel Engine size:OD:6-530mm WT:0.5-38.1mm Length:1.5-6m Steel Grade And Chemical component Unified digital code Grade Chemical Component(Quality Fraction)/% C Si Mn P S Cr Ni Cu No More Than U20103 10A 0.07~0.13 0.17~0.37 0.35~0.65 0.030 ...
Product Details
Highlight:
seamless steel pipe
,seamless carbon steel tube
Keyword:
Seamless Steel Tubes
Type:
Seamless Steel Tubes
Surface:
Oiled
Shape:
Round
Length:
3-12m
OD:
4-420m
Material:
10# 45# Q345
Terms Of Trade:
CIF FOB CFR
Product Description
TORICH GB/T3093 Q345 High-Pressure Seamless Steel Tubes For Diesel Engine
size:OD:6-530mm
WT:0.5-38.1mm
Length:1.5-6m
Steel Grade And Chemical component
| Unified digital code | Grade | Chemical Component(Quality Fraction)/% | |||||||
| C | Si | Mn | P | S | Cr | Ni | Cu | ||
| No More Than | |||||||||
| U20103 | 10A | 0.07~0.13 | 0.17~0.37 | 0.35~0.65 | 0.030 | 0.030 | 0.15 | 0.30 | 0.20 |
| U20203 | 20A | 0.17~0.23 | 0.17~0.37 | 0.35~0.65 | 0.030 | 0.030 | 0.25 | 0.30 | 0.20 |
| L03451 | Q345A | ≤0.20 |
≤0.55 | 1.00~1.60 | 0.030 | 0.030 | 0.30 | 0.30 | 0.20 |
The tolerance of OD and WT unit:mm
| Accuracy class | OD | Tolerance | ID | Tolerance |
| A | all | ±0.10 | ≤3.0 | +0.10 -0.20 |
| >3.0 | +0.10 -0.30 | |||
| B | all | ±0.10 | <2.0 ≥2.0 | ±0.05 ±0.10 |
| C | ≤3.0 >3.0 | ±0.025 ±0.050 | ||
| D | 6.0 | +0.05 0 | ||
| 7.0 |
Steel Grade and Chemical Component
| Unified digital code | Grade | Chemical Component(Quality Fraction)/% | |||||||
| C | Si | Mn | P | S | Cr | Ni | Cu | ||
| No more than | |||||||||
| U20103 | 10A | 0.07~0.13 | 0.17~0.37 | 0.35~0.65 | 0.030 | 0.030 | 0.15 | 0.30 | 0.20 |
| U20203 | 20A | 0.17~0.23 | 0.17~0.37 | 0.35~0.65 | 0.030 | 0.030 | 0.25 | 0.30 | 0.20 |
| L03451 | Q345A | ≤0.20 | ≤0.55 | 1.00~1.60 | 0.030 | 0.030 | 0.30 | 0.30 | 0.20 |
Mechanical Properties Of Pipes
| Grade | Strength of extension MPa | Yield Point MPa | Elongation % |
| No more than | |||
| 10A | 335~470 | 205 | 30 |
| 20A | 390~540 | 245 | 25 |
| Q345A | 470~630 | 345 | 22 |
Manufacturing Method:Steel should be manufactured in electric or oxygen converter.Steel Pipe should be manufactured by cold drawn seamless method.
Delivery State:After final cold drawn,steel tubes will be deliveried with heat treatment.
Test Item:Tensile test ,Cold head forging, test Hydraulic test, Eddy current test
Main Features:
high accuracy, excellent brightness, no oxidization on the outer and inner walls after heat treatment, high cleanness inside wall. The steel tube is able to stand high pressure. No deformation after cold bending, no crack after flaring and flattening . The complicated geometrical forming and machining can be realized.
Main Application:
to be used in hydraulic system, automobile parts and in the occasion where the high precision, brightness, cleanness and mechanical properties of the tube are required.
to be used in hydraulic system, automobile parts and in the occasion where the high precision, brightness, cleanness and mechanical properties of the tube are required.
