Name: DIN 2391 ST52 Seamless Steel Tube OD 5-420mm For Pneumatic Cylinder
Brand: TORICH INTERNATIONAL LIMITED
SKU: DIN 2391, EN 10305-1, SAE J524, ASTM A519 and GB3639
Price: 2,550.00 USD
Availability: InStock

Home > products > Seamless Steel Tube >

DIN 2391 ST52 Seamless Steel Tube OD 5-420mm For Pneumatic Cylinder

seamless steel pipe

precision stainless steel tubing

Place of Origin:

Zhejiang,China

Brand Name:

TORICH

Certification:

ISO9001 ISO14001 TS16949

Model Number:

DIN 2391, EN 10305-1, SAE J524, ASTM A519 and GB3639

Request A Quote

DIN 2391 ST52 Seamless Steel Tube OD 5-420mm For Pneumatic Cylinder

Product Details

Product Name:

DIN 2391 ST52 Seamless Steel Tube OD 5-420mm For Pneumatic Cylinder

Keyword:

ST52 Seamless Steel Tubes

Application:

Applicable To Hydraulic Pressure, Pneumatic Cylinder,oil Pump Barrel, Motor Body, Transmission Shaft, Etc.

Shape:

Round

Material:

ST52 ST52.3 E355 ST37 16Mn Q345B 1020

Delivery Condition:

OD:

5-420mm

WT:

0.5-50mm

Length:

Max 12000mm

Brand:

TORICH

Highlight:

seamless steel pipe

precision stainless steel tubing

Payment & Shipping Terms

Minimum Order Quantity

3 TONS

Price

negotiable

Packaging Details

DIN 2391 ST52 Seamless Steel Tube OD 5-420mm For Pneumatic Cylinder,packing in standard seaworthy packages

Delivery Time

20-45 DAYS

Payment Terms

T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability

5000 TONS PER MONTH

42CrMo Alloy Steel Boiler Tube Alloy Seamless Steel Pipe Tube For Boiler

Get Best Price

20MnG High Pressure Boiler Tube Alloy Seamless Pipe For Boilers Heat Exchangers

Get Best Price

ASTM A106 Hot Finished Seamless Tubing High-Temperature Seamless Carbon Steel Pipe

Get Best Price

video

40Mn2 20Cr 40Cr 15CrMo Carbon Steel / Alloy Steel Hot Rolled Steel Tube

Get Best Price

86-574-88086983

Contact Now

Product Description

DIN 2391 ST52 Seamless Steel Tube OD 5-420mm For Pneumatic Cylinder

Usage
Applicable to hydraulic pressure, pneumatic cylinder,oil pump barrel, motor body, transmission shaft, etc.

Honed tube for hydraulic cylinder
Standard	DIN2391, EN10305, JIS G3445, ASTM A519, GB/T 8713...
Material	ST45, ST52, E355, E355SR, STKM13C, SAE1026, 20#, Q235B, CK45...
Heat treatment	BK+S
Specification	Outer diameter(mm)	Inner diameter(mm)
	50-300mm	40-250
I.D Tolerance	H8-H9
Length	3-9m (Customers usually choose the 4~5.8m)
Straightness	1/1000
ID roughness	RA 0.4micron(max)
Technology	Honed & SRB(SKIVED AND ROLLER BURNISHED )
Scope	Honed tube for hydraulic cylinder, swivel crane, injection machine and construction machine application

Process
Raw materials- Cold drawn/rolled- Heat treatment(BKS)- Honed or SRB- packing

Steel Grade
ST52, ST52.3, E355, SAE1026, Q345B.
*Low temperature impact test upon request (27J/-20°C).

Size
Processing Cylinder diameterLength /mmStraightnessSize accuracyWall thickness/mmInner boreroughness
Cold Drawn/RolledID28~OD400≤12M0.3~1.0m m/m H8-H11±5%0.8~1.6um
Honed/SRBID30~OD500≤12M0.3~1.0m m/m H8±5%0.4~0.8um

Packing: With anti-rust oil on inner diameter of each pipe,tube caps on both ends, hexagonal bundles of max 3,000 kg with several steel strips, nylon bag and waterproof paper package each bundle. Of course, customers can customize other packing way.
