Seamless Steel Tube

Torich 400mm 6' SCH80 ASTM A106 Gr B GI S40 Carbon Steel Pipe Size range: O.D.:50-500mm W.T.:5-60mm L:max12000mm Steel Grade and Chemical Compositions: Steel Grade C Mn P S Si Cr Cu Mo Ni V max 　 max max min max max max max max A 0.25 0.27~0.93 0.035 0.035 0.10 0.40 0.40 0.15 0.40 0.08 B 0.30 0.27~1.06 0.035 0.035 0.10 0.40 0.40 0.15 0.40 0.08 C 0.35 0.27~1.06 0.035 0.035 0.10 0.40 0.40 0.15 0.40 0.08 Mechanical Properties: Grade Tensil Strength Mpa Yield Point Mpa Elongtatio

Products Description Steel Pipe DIN 1629 St37.0 St52.0 Low Carbon Seamless Steel Tube Low Carbon Steel Pipe DIN 1629 St37.0 t52.0 Unalloyed Seamless Steel Tube Standard: DIN 1629 Seamless circular unalloyed steel tubes subject to special requirements Applications: used in construction of chemical plant,vessels,pipework and for general mechanical engineering purposes. Production Method: Seamless Cold Drawn/Rolling or Hot Rolling Size range: O.D.:20-660mm W.T.:1-60mm L

SA192 Seamless Carbon Tubes for Boilers and Heat-Exchangers Thread Steel Pipes Applications: Seamless Carbon Boiler Tubes Size range: O.D.:5-420mm W.T.:0.5-50mm L: according to customer's requirement (Max12m) Steel Grade and Chemical Compositions: C 0.06-0.18 Mn 0.27-0.63 P ≤0.035 S ≤0.035 Si ≤0.25 Mechanical Properties Tensil Streghth: min ksi[Mpa] 47[325] Yield Point: min ksi[Mpa] 26[180] Elongation: ≥35% Package: 1) Bundle 2) In Bulk 3) Bags 4) As Clients' Requirements

ASTM SAME SA192 Seamlesss Steel Tube for Boilers Applications: for Boilers,Superheaters, Heat-Exchangers, High-pressure Boilers, Steam Boilers Cold Condensers and High-Pressure Services, High-Temperature Services for Boiler Constructions Manufacture: Tubes are manufactured by seamless process and both hot finished and cold finished are applicable. seamless boiler steel tube Size: OD 12.7-177.8mm WT 2.2-25.4mm alloy steel boiler tube Heat treatment: Hot finished tubes need not

TORICH Din 17175 St45.8 STKM11A SAE4130 Internal Polish Gas and Spring Use BKS Honed Steel Tube Spring Seamless Steel Pipe Description Competitive Price For ASTM A106B /ASTM A53B / API 5L Gr.B Seamless Steel Pipe Supply Capacity 10000 tons/year Process Method Hot Rolled and cold drawn seamless steel pipe Out Diameter 6-910 mm Wall Thickness 0.6-60mm Length SPECIFIC OR AT RANDOM as required Steel Grade ASTM A106 B , A 53B, API 5L B, 20#, 45# , 40Cr Standards ASTM / ASME, GB,

TORICH ASTM A519 JIS SCM430 DIN 30GrMo4 SAE4130 Chrome Moli Alloy Round Seamless AISI4130 Steel Tube For Bicycle Motorcycle Frame 1. Grade: JIS SCM430, DIN 30GrMo4, SAE4130/ AISI4130 2. Size: O.D.:6-350mm W.T.:1-35mm L:max12000mm 3. Standard: ASTM A519 4. Certification: ISO9001,TS16949 5. Applications: for Auto industry/for machinery use/Motorcycle frame 6. Chemical Composition and Mechanical Property: Chemical Composition(%) Mechanical Property C Si Mn S P Cr Ni Cu Mo Yield

DIN 2391 ST52 Seamless Steel Tube OD 5-420mm For Pneumatic Cylinder Usage Applicable to hydraulic pressure, pneumatic cylinder,oil pump barrel, motor body, transmission shaft, etc. Honed tube for hydraulic cylinder Standard DIN2391, EN10305, JIS G3445, ASTM A519, GB/T 8713... Material ST45, ST52, E355, E355SR, STKM13C, SAE1026, 20#, Q235B, CK45... Heat treatment BK+S Specification Outer diameter(mm) Inner diameter(mm) 50-300mm 40-250 I.D Tolerance H8-H9 Length 3-9m (Customers

TORICH High Tensile Thin Wall 34mm MS 1010 Plastic End Caps for AISI 1020 46mm 4130 Carbon Seamless Mild ASTM A513 1026 DOM Tube TORICH High Tensile Thin Wall 34mm MS 1010 Plastic End Caps for AISI 1020 46mm 4130 Carbon Seamless Mild ASTM A513 1026 DOM Tube Steel Grade/Steel Material: E155 E195 E235 E275 E355 Delivery Condition: N Normalized Size Range: O.D.:4-80mm W.T.:1-8mm L:max 6000mm Characteristic: Good concentricity Good OD and ID tolerance High precision Stable

JIS 3463 SUS304TB SUS304LTB SUS 310STB SUS316TB SUS316LTB seamless steel tubes use for boiler and heat exchanger Material :SUS304TB　SUS304LTB　SUS316TB　SUS316LTB　SUS317TB　SUS317LTB　SUS310TB　SUS310STB　SUS321TB　SUS321HTB　SUS347TB Yeild strength ≥175Mpa or ≥206Mpa Tensile strength ≥481Mpa or ≥521Mpa Elongation ≥27% or ≥35% Flattening test H=1.09t/(0.09+t/D) Flaring test 60° 12%D Grain size JIS G051 Hydrostatic test P=2Rt/D It can be taken place by Nondestructive flaw detection
