Nickel - Base Superalloy Steel Pipe Incoloy A - 286 7.94 G / Cm³ Alloy Steel Tubing

Basic Properties
Place of Origin: China
Brand Name: Torich
Certification: CE PED
Model Number: Alloy Steel Pipe Incoloy A-286
Trading Properties
Minimum Order Quantity: 1000kg
Price: negotiable
Payment Terms: L/C, T/T
Supply Ability: 200 tons per year
Product Summary
Alloy Steel Pipe Incoloy A-286 Charactistic of material: Chemical composition: C: ≤0.08 Cr:13.5-16.0 Ni:24.0-27.0 Mo:1.00-1.50 Ti:1.75-2.30 Fe:remaind V:0.10-0.50 B:0.001-0.010 Mn:1.00-2.00 Al ≤0.04 Si:≤1.00 P:≤0.030 S:≤0.020 Fe-25Ni-15Cr base superalloy + molybdenum,titanium,aluminum,Vanadium ...

Product Details

Highlight:

alloy steel tube

,

alloy steel seamless tube

Product Description

Alloy Steel Pipe Incoloy A-286



Charactistic of material:



Chemical composition:



C: ≤0.08 Cr:13.5-16.0 Ni:24.0-27.0 Mo:1.00-1.50 Ti:1.75-2.30 Fe:remaind V:0.10-0.50 B:0.001-0.010 Mn:1.00-2.00 Al ≤0.04 Si:≤1.00 P:≤0.030 S:≤0.020



Fe-25Ni-15Cr base superalloy + molybdenum,titanium,aluminum,Vanadium



Physical properties:



Density 7.94 g/cm³ 0.287 lb/in³
Melting Point 1430°C 2600°F
Coefficient of Expansion 16.4 μm/m °C (20 - 100°C) 9.1 x 10-6 in/in °F (70 - 212°F)
Modulus of Rigidity 71.5 kN/mm² 10370 ksi
Modulus of Elasticity 205 kN/mm² 29733 ksi



Incoloy A-286 heat-treatment

Variety of materials Heat Treatment
Bar, pie 980~1000℃,1~2h,Oil cooler+700~720℃,12~16h,Air Cooling
Hot-rolled sheet, cold-rolled plate 980~1000℃,Air Cooling+700~720℃,12~16h,Air Cooling
Cold drawn bar 980~1000℃,1~2h,Oil cooler+700~720℃,16h,Air Cooling
Ring blanks 980~990℃,1~2h,Oil cooler+700~720℃,16h,Air Cooling
Cold heading cold drawing 980~1000℃,Water or oil cooling+700~720℃,16h,Air Cooling





High yield strength and durability

creep strength

good processing plasticity and satisfactory welding performance



Incoloy A-286 is use in aerospace area.



Related standard:

SAE AMS5731 Steel, Corrosion and Heat-Resistant, Bars, Wire, Forgings, Tubing, and Rings, 15Cr - 25.5Ni - 1.2Mo - 2.1Ti



SAE AMS 5732 Steel, Corrosion and Heat-Resistant, Bars, Wire, Forgings, Tubing, and Rings15Cr - 25.5Ni - 1.2Mo - 2.1Ti - 0.006B - 0.30VConsumable Electrode Melted1800 °F (982 °C) Solution and Precipitation Heat Treated



AMS 5737

AMS 5525



Similar garde:UNSS66286 (USA), ZbNCT25 (France), PQA286 (USA)
