ASTM Alloy Steel Grade Inconel Tubing , Good Tensile Properties Inconel 625 Tube

Basic Properties
Place of Origin: China
Brand Name: Torich
Certification: CE PED
Model Number: Inconel 625
Trading Properties
Minimum Order Quantity: 1000kg
Price: 6000-20000 USD per ton
Payment Terms: L/C, T/T
Supply Ability: 200 tons per year
Product Summary
Inconel Steel Tubes are produced with Alloy Steel Grade Inconel 625 Chemical component:% max C:≤0.10 Cr:20.0-23.0 Co:≤1.00 Mo:8.0-10.0 Al :≤0.40 Ti:≤0.40 Nb:3.15-4.15 Fe:≤5.00 Mn:≤0.50 Si:≤050 P:≤0015 S: ≤0.015 Cu:≤0.07 Physical comstants : Density,lb/cu in 0.305 gram/cc 8.44 Characteristic of ...

Product Details

Highlight:

inconel 600 tube

,

inconel 718 tube

Material: 625
Standard: ASTM B444
OD: 1-450mm
Production Method: Cold Drawn
Type: Seamless
MTC: EN10204.3.2B
Product Description

Inconel Steel Tubes are produced with Alloy Steel Grade Inconel 625





Chemical component:% max

C:≤0.10 Cr:20.0-23.0 Co:≤1.00 Mo:8.0-10.0 Al :≤0.40 Ti:≤0.40 Nb:3.15-4.15

Fe:≤5.00 Mn:≤0.50 Si:≤050 P:≤0015 S: ≤0.015 Cu:≤0.07



Physical comstants :

Density,lb/cu in 0.305 gram/cc 8.44



Characteristic of material:

excellent resistance to corrosion

oxidation resistance to engage

good tensile properties from cryogenic to 980℃

good fatigue properties from cryogenic to 980℃



Inconel 625 Mechanical properties.

Variety Tensile Properties Lasting performance Hardness
θ/℃ σb/MPa σP0.2/MPa δ5/% θ/℃ σ/MPa t/h δ5/%
great than great than
Bar① 20 830 410 30 815 114 23 15 HB≤290
Sheet② 20 830 410 30 815 114 23 15 HV≤305
Bar 20 830 410 30 Q/3B 4078-1992 -
Sheet 20 825 415 30 Q/3B 4077-1992 -
Pipe 20 825 415 35 Q/3B 4080-1992 HRC≤25

① Standard Z9-0105-1990. ② standard Z9-0104-1990 and GJB 3317-1998.



Standard:



Tubes standard : ASTM B444 Nickel-Chromium-Molybdenum-Columbium Alloys(UNS N06625 and UNS N06852)and Nickel-Chromium-Molybdenum-Silicon Alloy(UNS N06219)Pipe and Tube

                          ASTM B622 Seamless Nickel and Nickel-Cobalt Alloy pipe and Tubes.



Plate sheet and strip standard :ASTM B443 Nickel-Chromium-Molybdenum-Columbium Alloy (UNS N06625 and UNS N06852)and Nickel-Chromium-Molybdenum-Silicon Alloy(UNS N06219)Plate,Sheet,and strip



Forging: ASTM B564 Nickel Alloy Forgings.





Apply for aircraft engine parts,sea water applications,engine exhaust systems, fuel and hydraulic line tubing.
