ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation
Basic Properties
Place of Origin:
Zhejiang/China
Brand Name:
TORICH
Certification:
ISO9001 ISO 14001 TS16949
Model Number:
ASTM A213
Trading Properties
Minimum Order Quantity:
1Ton
Price:
1000-1300 USD/Ton
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:
60000 Ton/Tons per Year
Product Summary
ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation Material ASTM A213 covers seamless ferritic and austenitic alloy-steel boiler, superheater, and heat-exchanger tubes. Among these, seamless austenitic stainless steel pipes are widely used due to their excellent ...
Product Details
Highlight:
Seamless Austenitic Stainless Steel Pipe
,PVC Coated Steel Pipe Seamless
Certification:
ISO,SGS,Other,ROHS
Steel Grade:
300 Series,200 Series,400 Series,TP316,200/300 Series
Application:
Insulation
Type:
Welded,Seamless,seamless And Welded,round
Standard:
GB,ASTM,DIN,AISI,JIS
Thickness:
0.4-30mm,0.25-2.5mm,1mm-40mm,0.2-0.25,0.2mm
Outer Diameter:
6mm-219mm/10mmx10mm,1mm-1500mm,3mm Upto 23mm,10*10mm-100*100mm,6-760mm
Length:
1m-12m,6m Or As Customers' Request,30mm Or Custom,0-12m,2.5-8m
Product Description
ASTM A213 PVC Coated Steel Pipe Seamless Austenitic Stainless Steel Pipe For Insulation
Material
ASTM A213 covers seamless ferritic and austenitic alloy-steel boiler, superheater, and heat-exchanger tubes. Among these, seamless austenitic stainless steel pipes are widely used due to their excellent corrosion resistance, high-temperature strength, and ductility. The base material is typically an austenitic stainless steel, with popular grades including 304, 304L, 316, and 316L.
The PVC coating on steel pipes serves as a protective layer, enhancing corrosion resistance especially for insulation applications by providing additional barrier protection against moisture, chemicals, and physical damage.
Specification
- Standard: ASTM A213
- Type: Seamless Austenitic Stainless Steel Pipe
- Coating: PVC (Polyvinyl Chloride) coating for corrosion protection and insulation support
- Dimensions: Available as per ASTM A213 dimension standards for OD and wall thickness
- Grades: Commonly 304, 304L, 316, and 316L stainless steel
- Heat Treatment: Solution annealed and cold worked depending on grade and application
Chemical Composition
| Element | 304 (%) | 304L (%) | 316 (%) | 316L (%) |
|---|---|---|---|---|
| Carbon (C) | 0.08 max | 0.03 max | 0.08 max | 0.03 max |
| Manganese (Mn) | 2.00 max | 2.00 max | 2.00 max | 2.00 max |
| Silicon (Si) | 1.00 max | 1.00 max | 1.00 max | 1.00 max |
| Phosphorus (P) | 0.045 max | 0.045 max | 0.045 max | 0.045 max |
| Sulfur (S) | 0.030 max | 0.030 max | 0.030 max | 0.030 max |
| Chromium (Cr) | 18-20 | 18-20 | 16-18 | 16-18 |
| Nickel (Ni) | 8-10 | 8-12 | 10-14 | 10-14 |
| Molybdenum (Mo) | — | — | 2-3 | 2-3 |
Mechanical Properties
| Property | 304 | 304L | 316 | 316L |
|---|---|---|---|---|
| Tensile Strength (MPa) | 515 min | 485 min | 515 min | 485 min |
| Yield Strength (MPa) | 205 min | 170 min | 205 min | 170 min |
| Elongation (%) | 40 min | 40 min | 40 min | 40 min |
| Hardness (HRB) | Max 95 | Max 95 | Max 95 | Max 95 |
Key Features
- Corrosion Resistance: Austenitic stainless steel composition provides excellent resistance to rust, pitting, and crevice corrosion.
- Seamless Construction: Provides superior strength and reliability with no weld seams, suitable for high-pressure applications.
- PVC Coating: Enhances corrosion resistance, protects against external environmental factors, and supports thermal insulation.
- High Temperature Resistance: Suitable for boiler and heat exchanger applications in high temperature environments.
- Ductility and Toughness: Maintains strength even in cryogenic and low-temperature applications.
- Low Maintenance: Extended service life with reduced maintenance needs due to protective coating.
Application
- Boiler tubes and superheater tubes in power plants
- Heat exchangers and condensers in chemical processing plants
- Petroleum refineries
- HVAC systems with insulation requirements
- Industrial piping requiring corrosion protection and insulation
- Structural piping in marine and offshore environments
Equivalent Grades
| ASTM A213 Grade | ASTM A312 Equivalent | EN Standard Equivalent | JIS Equivalent |
|---|---|---|---|
| TP304 | TP304 | 1.4301 (AISI 304) | SUS304 |
| TP304L | TP304L | 1.4307 (AISI 304L) | SUS304L |
| TP316 | TP316 | 1.4401 (AISI 316) | SUS316 |
| TP316L | TP316L | 1.4404 (AISI 316L) | SUS316L |
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
·
