S235JR Galvanized Square Steel Pipe Cold Formed Welded Steel Tube For Structural
Basic Properties
Place of Origin:
Zhejiang
Brand Name:
TORICH
Certification:
ISO9001 ISO 14001 TS16949
Model Number:
S235JR EN 10219
Trading Properties
Minimum Order Quantity:
1 Ton
Price:
600-1000 USD/Ton
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:
60000 Ton/Tons per Year
Product Summary
S235JR Galvanized Square Steel Pipe Cold Formed Welded Steel Tube For Structural Material The S235JR galvanized square metallic pipe is made from S235JR grade carbon metal. This steel is labeled beneath the european wellknown EN 10219 and is known for its extremely good weldability and mechanical ...
Product Details
Highlight:
S235JR Welded Square Steel Pipe
,Cold Formed Square Steel Pipe
,Structural Welded Square Steel Pipe
Application:
Struetural
Thickness:
1-100 Mm
Technique:
Cold Drawn,Hot Rolled,Cold Rolled,ERW,Hot Rolled/Cold Drawn
Grade:
S235JR
Outer Diameter(Round):
30 - 426 Mm
Length:
6M Or As Requirement,
Standard:
ASTM EN JGOST JIS GB ISO
Surface:
Galvanized Coated,oil,zinc Coated 200-700g/sqm,Satin Or Mirror,Paint
Product Description
S235JR Galvanized Square Steel Pipe Cold Formed Welded Steel Tube For Structural
Material
The S235JR galvanized square metallic pipe is made from S235JR grade carbon metal. This steel is labeled beneath the european wellknown EN 10219 and is known for its extremely good weldability and mechanical homes. The galvanization gives corrosion resistance, making it appropriate for outside and structural packages.
Specification
- Grade: S235JR
- Shape: Square, but can be customized
- Manufacturing Process: Ccold bending, welding, etc.
- Surface: hot dip galvanized
- Sizes: various wall thickness, outer diameter and length can be selected. OEM/ODM can also be customized according to drawings
- Standard: EN 10219 or other
Chemical Composition
| Element | % Composition (Typical) |
|---|---|
| Carbon (C) | ≤ 0.17 |
| Manganese (Mn) | ≤ 1.40 |
| Phosphorus (P) | ≤ 0.035 |
| Sulfur (S) | ≤ 0.035 |
| Nitrogen (N) | ≤ 0.012 |
| Copper (Cu) | ≤ 0.55 |
Mechanical Properties
| Property | Value |
|---|---|
| Yield Strength (ReH) | ≥ 235 MPa |
| Tensile Strength (Rm) | 360 – 510 MPa |
| Elongation A (%) | ≥ 26 % |
| Impact Energy (Charpy V-notch) | 27 J at 20°C |
Key Features
- Steel pipes that can be welded and flanged
It is low carbon steel so the structure is good
The surface is galvanized for a shiny appearance and improved corrosion resistance
High cost performance
Equivalent Grades
| Standard | Equivalent Grade |
|---|---|
| ASTM | A36 (similar properties) |
| EN | S235JR |
| GOST (Russia) | St3sp, St3ps |
| JIS (Japan) | SS400 |
| GB (China) | Q235 |
Application
S235JR galvanized square steel pipe is very useful in the structural field, and also has users in other application fields. You can see it below.
- Automobile chassis and supporting parts
Agricultural machinery
Green belts and gates
Large outdoor billboards
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
·
