15Mo3 Seamless Boiler Tube Alloy Steel Seamless Pipe For Heat Exchangers
Basic Properties
Place of Origin:
Zhejiang/China
Brand Name:
TORICH
Certification:
ISO9001 ISO 14001 TS16949
Model Number:
15Mo3
Trading Properties
Minimum Order Quantity:
1Ton
Price:
Negotiable
Payment Terms:
L/C,D/A,D/P,Western Union,T/T,MoneyGram
Supply Ability:
60000 Ton/Tons per Year
Product Summary
15Mo3 Seamless Boiler Tube Alloy Steel Seamless Pipe For Heat Exchangers Seamless boiler tubes made from 15Mo3 alloy steel are critical components in a range of industrial applications where high temperature and pressure are involved. These pipes are particularly valued for their durability, heat ...
Product Details
Highlight:
Pipe Heat Exchangers Boiler Tube
,15Mo3 Seamless Boiler Tube
,Heat Exchangers Alloy Steel Seamless Pipe
Porcess Service:
Bending, Punching,cutting
Material:
Alloy Steel
Test:
SGS/BV/TUV
Alloy Or Not:
Is Alloy
Technics:
Cold Drawn
Standards:
DIN 17175
Alloy Specification:
All
Particle:
Customizable
Ends:
Plain, Beveled, Threaded
Application:
Heat Exchangers Boiler
Standard:
ASTM,DIN,GB,JIS,API
Thickness:
0.1mm-100mm
Certification:
API,CE,ISO,ISO9001-2008,ISO9001
Technique:
Cold Drawn,Hot Rolled,Cold Rolled,ERW,Hot Rolled/Cold Drawn
Surface Treatment:
Customerized
Grade:
15Mo3
Alloy Or Not:
S Alloy
Section Shape:
Round,Rectangular
Outer Diameter(Round):
17 - 426 Mm
Special Pipe:
Thick Wall Pipe
Secondary Or Not:
Non-secondary
Grade Group:
16Mn
Length:
6M Or As Requirement,As Customer's Require
Product Name:
Steel Tubes,Cold Drawn Precision Round Carbon Steel Tube
Type:
Seamless
Product Description
15Mo3 Seamless Boiler Tube Alloy Steel Seamless Pipe For Heat Exchangers
Seamless boiler tubes made from 15Mo3 alloy steel are critical components in a range of industrial applications where high temperature and pressure are involved. These pipes are particularly valued for their durability, heat resistance, and excellent mechanical properties. Below is a comprehensive overview of 15Mo3 seamless boiler tubes, covering material specifications, key features, and their application in various industries.
Material
15Mo3 is a low-alloy steel predominantly used for manufacturing boiler tubes and pipes that can withstand high temperatures and harsh environmental conditions. It incorporates molybdenum, enhancing corrosion and pitting resistance, making it an ideal choice for heat exchangers and similar applications.
Specification
- Standard: DIN 17175
- Grade: 15Mo3
- Form: Seamless pipes and tubes
- Outer Diameter: Typically ranges from 10.2mm to 711mm
- Wall Thickness: Ranges from 1.2mm to 60mm
- Length: Available in single random, double random, or as required by the client
- Tolerance: As per applicable standard and customer requirement
Key Features
- High Temperature Resistance: Excellent performance under high temperature conditions.
- Corrosion Resistance: Effective against oxidation and pitting in hostile environments.
- Mechanical Strength: Superior strength ensures reliability in pressure vessels and heat exchangers.
- Versatility: Can be tailored to specifications for various industries and applications.
Chemical Composition
The table below outlines the typical chemical composition for 15Mo3 seamless boiler tubes:
| Element | Composition (Max %) |
|---|---|
| Carbon (C) | 0.12 - 0.20 |
| Silicon (Si) | 0.20 - 0.35 |
| Manganese (Mn) | 0.40 - 0.90 |
| Phosphorus (P) | 0.025 max |
| Sulfur (S) | 0.025 max |
| Molybdenum (Mo) | 0.25 - 0.35 |
Mechanical Properties
Below are the typical mechanical properties for 15Mo3 tubes:
| Property | Value |
|---|---|
| Tensile Strength | 450 - 600 MPa |
| Yield Strength | Min 270 MPa |
| Elongation | 22% (min) |
Similar Standards and Steel Grades
The 15Mo3 is comparable to several international standards and steel grades such as:
- ASTM: A204 Grade A
- EN: 16Mo3
- GOST: 12KhM
These equivalents can be interchangeably used depending on the inter-industry specifications and requirements.
Application
15Mo3 seamless boiler tubes are widely used in various industries, including:
- Power Plants: Integral to the design of boilers and related components that require sustained high temperature and pressure conditions.
- Petrochemical Industry: Used in heat exchangers due to their resistance to corrosion under chemical exposure.
- Industrial Boilers: Part of heating systems in various manufacturing processes.
TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.
The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.
The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.
Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
