| Brand Name: | TORICH |
| Model Number: | ASTM B829 |
| MOQ: | 1 Ton |
| Price: | Negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 60000 Ton/Tons per Year |
ASTM B829 is a standard specification for nickel alloys, specifically focusing on seamless pipes. This specification covers Monel 400 and Incoloy 625, which are renowned for their excellent corrosion resistance and mechanical properties. These alloys are commonly used in industries where high performance and durability are required.
The chemical composition of Monel 400 and Incoloy 625 is crucial for their performance characteristics. Below is a table presenting their typical chemical composition:
| Element | Monel 400 (%) | Incoloy 625 (%) |
|---|---|---|
| Nickel (Ni) | 63.0 min | 58.0 min |
| Copper (Cu) | 28.0 - 34.0 | - |
| Chromium (Cr) | - | 20.0 - 23.0 |
| Molybdenum (Mo) | - | 8.0 - 10.0 |
| Iron (Fe) | 2.5 max | 5.0 max |
| Manganese (Mn) | 2.0 max | 0.50 max |
| Silicon (Si) | 0.50 max | 0.50 max |
| Carbon (C) | 0.30 max | 0.10 max |
The mechanical properties of these alloys are critical for their application in demanding environments. The table below outlines the typical mechanical properties:
| Property | Monel 400 | Incoloy 625 |
|---|---|---|
| Tensile Strength (MPa) | 550 min | 690 min |
| Yield Strength (MPa) | 240 min | 275 min |
| Elongation (%) | 30 min | 30 min |
| Hardness (Rockwell) | B75 max | B100 max |
A: manufacturer,also can do trading.
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
