DIN 17123 StE255 Structural Steel Pipe Welded Circular Fine Grain Welded Steel Tubes For Structural Steelwork
Basic Properties
Place of Origin:
Zhejiang/China
Brand Name:
TORICH
Certification:
ISO 9001 ISO14001 TS16949
Model Number:
DIN 17123
Trading Properties
Minimum Order Quantity:
1 Ton
Price:
Negotiable
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
60000 Ton/Tons per Year
Product Summary
DIN 17123 StE255, StE285, StE355, StE420, StE460 Structural Steel Pipe Welded Circular Fine Grain Welded Steel Tubes for Structural Steelwork Material Specification DIN 17123 specifies the requirements for welded circular fine grain steel tubes used in structural steelwork. These tubes are designed ...
Product Details
Highlight:
DIN 17123 Welded Steel Tubes
,Structural Welded Steel Tubes
,Fine Grain Welded Steel Tubes
Section Shape:
Round/Square/Rectangular/Oval.etc,according To Customer
Secondary Or Not:
Non-secondary
Technique:
ERW,Hot Rolled,Cold Rolled,Extruded
Thickness:
0.4 - 50 Mm
Application:
Structure Pipe
Surface Treatment:
Galvanized
Alloy Or Not:
Is Alloy
Standard:
ASTM,GB,JIS,BS
Grade:
StE255 TStE255 EStE255 StE285 TStE285 EStE285 StE355 TStE355 EStE355 StE420 TStE420 EStE420 StE460 TStE460 EStE460
Special Pipe:
Thick Wall Pipe
Length:
1-12m/as Customers' Requests
Surface:
Galvanized Coated
Outer Diameter(Round):
20 - 677 Mm
Product Name:
ERW Steel Pipes,galvanized Round Pipe
Product Description
DIN 17123 StE255, StE285, StE355, StE420, StE460 Structural Steel Pipe
Welded Circular Fine Grain Welded Steel Tubes for Structural Steelwork
Material Specification
DIN 17123 specifies the requirements for welded circular fine grain steel tubes used in structural steelwork. These tubes are designed to provide high strength and durability, making them suitable for various construction applications. The standard covers several steel grades, including StE255, StE285, StE355, StE420, and StE460, each offering distinct mechanical properties to cater to different structural needs.
Key Features
- High Strength: The steel grades specified under DIN 17123 offer excellent tensile strength, making them ideal for load-bearing applications.
- Fine Grain Structure: The fine grain structure enhances the toughness and ductility of the steel tubes.
- Weldability: These steel tubes are designed for easy welding, facilitating their use in complex structural designs.
- Corrosion Resistance: The chemical composition provides a degree of resistance to corrosion, extending the lifespan of the structures.
- Versatility: Suitable for various structural applications, including bridges, buildings, and industrial frameworks.
Chemical Composition
The chemical composition of these steel grades is crucial for their performance. Below is a table presenting the typical chemical composition for each grade:
| Element | StE255 | StE285 | StE355 | StE420 | StE460 |
|---|---|---|---|---|---|
| C | ≤ 0.20% | ≤ 0.20% | ≤ 0.20% | ≤ 0.20% | ≤ 0.20% |
| Si | ≤ 0.55% | ≤ 0.55% | ≤ 0.55% | ≤ 0.55% | ≤ 0.55% |
| Mn | 1.00-1.60% | 1.00-1.60% | 1.00-1.60% | 1.00-1.60% | 1.00-1.60% |
| P | ≤ 0.035% | ≤ 0.035% | ≤ 0.035% | ≤ 0.035% | ≤ 0.035% |
| S | ≤ 0.035% | ≤ 0.035% | ≤ 0.035% | ≤ 0.035% | ≤ 0.035% |
Mechanical Properties
The mechanical properties of these steel grades determine their suitability for different structural applications. The table below outlines the typical mechanical properties:
| Property | StE255 | StE285 | StE355 | StE420 | StE460 |
|---|---|---|---|---|---|
| Yield Strength (MPa) | ≥ 255 | ≥ 285 | ≥ 355 | ≥ 420 | ≥ 460 |
| Tensile Strength (MPa) | 370-510 | 410-550 | 470-630 | 520-680 | 550-720 |
| Elongation (%) | ≥ 20 | ≥ 19 | ≥ 18 | ≥ 17 | ≥ 16 |
Steel Grade
The steel grades covered under DIN 17123 are designed to meet various structural requirements:
- StE255: Suitable for general structural applications with moderate strength requirements.
- StE285: Offers slightly higher strength, suitable for more demanding structural applications.
- StE355: Provides a balance of strength and ductility, ideal for a wide range of structural uses.
- StE420: High-strength steel suitable for heavy-duty structural applications.
- StE460: Offers the highest strength, ideal for the most demanding structural environments.
Application
These steel tubes are widely used in:
- Construction of bridges and buildings
- Industrial frameworks and supports
- Structural components in machinery
- Infrastructure projects requiring high-strength materials
Possible Alternative Grades
Depending on specific requirements, alternative steel grades may be considered:
- EN 10219 S355J2H: Offers similar mechanical properties and is often used in structural applications.
- ASTM A500 Grade C: A North American standard that provides comparable strength and ductility.
- BS 4360 Grade 50D: A British standard with similar applications in structural steelwork.
TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.
The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.
The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.
Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
