ASTM A1006 Gr.60 Welded Steel Tube Black Plain End Laser Beam Welded For General Purpose
Product Details
Laser Beam Welded Steel Tube
,ASTM A1006 Welded Steel Tube
,Black Plain End Welded Steel Tube
ASTM A1006 Grade 35 50 60 70 80 Welded Steel Tube Black Plain End Laser Beam Welded For General Purpose
Introduction
ASTM A1006 is a specification that covers welded steel tubes for general purposes. These tubes are produced using laser beam welding technology, which ensures high precision and quality. The grades specified in this standard include Grade 35, 50, 60, 70, and 80, each designed to meet different mechanical property requirements.
Material
The material used in ASTM A1006 welded steel tubes is typically low carbon steel, which provides excellent weldability and ductility. The tubes are available in various sizes and wall thicknesses, making them suitable for a wide range of applications.
Specification
The specification outlines the requirements for the manufacturing process, dimensions, tolerances, and testing methods for the welded steel tubes. It ensures that the products meet the necessary quality standards for structural and general-purpose applications.
Chemical Composition
| Grade | Carbon (C) | Manganese (Mn) | Phosphorus (P) | Sulfur (S) | Silicon (Si) |
|---|---|---|---|---|---|
| 35 | ≤ 0.26% | 0.60 - 0.90% | ≤ 0.04% | ≤ 0.05% | ≤ 0.40% |
| 50 | ≤ 0.26% | 0.60 - 0.90% | ≤ 0.04% | ≤ 0.05% | ≤ 0.40% |
| 60 | ≤ 0.26% | 0.60 - 0.90% | ≤ 0.04% | ≤ 0.05% | ≤ 0.40% |
| 70 | ≤ 0.26% | 0.60 - 0.90% | ≤ 0.04% | ≤ 0.05% | ≤ 0.40% |
| 80 | ≤ 0.26% | 0.60 - 0.90% | ≤ 0.04% | ≤ 0.05% | ≤ 0.40% |
Mechanical Properties
| Grade | Yield Strength (ksi) | Tensile Strength (ksi) | Elongation (%) |
|---|---|---|---|
| 35 | 35 | 55 - 75 | 20 |
| 50 | 50 | 65 - 85 | 20 |
| 60 | 60 | 70 - 90 | 20 |
| 70 | 70 | 75 - 95 | 20 |
| 80 | 80 | 85 - 105 | 20 |
Application
ASTM A1006 welded steel tubes are widely used in various applications, including:
- Construction: Structural components in buildings and bridges.
- Manufacturing: Frames and supports for machinery and equipment.
- Automotive: Chassis and structural parts in vehicles.
- General Purpose: Various applications requiring durable and reliable steel tubing.
These tubes are favored for their strength, versatility, and ability to be customized for specific needs. The laser beam welding process enhances the quality and integrity of the welds, making them suitable for demanding applications.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
