DIN 2393 St37-2 Welded Steel Tube Precision Cold Drawn Welded Steel Pipe For Sleeve
Product Details
DIN 2393 St37-2 welded steel tube
,Precision welded steel tube
,welded pipe For Sleeve
DIN 2393 St37-2 Welded Steel Tube Precision Cold Drawn Welded Steel Pipe For Sleeve
Material
The DIN 2393 St37-2 Welded Steel Tube is known for its precision and reliability. Utilizing cold drawn technology, this steel pipe is tailored for sleeve applications. Its material composition and design ensure durability and functionality in various industrial scenarios.
Specification
- Material: St37-2 Steel
- Standard: DIN 2393
- Type: Welded Steel Tube
- Production Method: Cold Drawn Welded
Key Features
- Precision Engineering: Designed for accuracy and consistent performance.
- Durability: Manufactured to withstand rugged industrial environments.
- Versatility: Suitable for diverse sleeve applications.
- Uniformity: Consistent wall thickness and diameter.
Chemical Composition
| Element | Percentage Composition |
|---|---|
| Carbon (C) | 0.17-0.20% |
| Silicon (Si) | 0.17-0.35% |
| Manganese (Mn) | 0.35-0.65% |
| Phosphorus (P) | 0.040% max |
| Sulfur (S) | 0.040% max |
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | 340-470 MPa |
| Yield Strength | 235 MPa min |
| Elongation | 25% min |
| Hardness | 121 HB max |
Steel Grade
The Steel Grade St37-2 conforms to DIN 2393 standards and provides reliable performance in demanding conditions.
Application
The DIN 2393 St37-2 Welded Steel Tube is widely used in industrial applications requiring precision and strength, especially in sleeve manufacturing. Its cold drawn design ensures consistent quality and dimensional accuracy, making it suitable for various engineering projects.
Possible Alternative Grades
- St44-2 Welded Steel Tube
- St52-3 Welded Steel Tube
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
