GB/T 32958 Stainless Steel Tube Stainless Steel Clad Pipes For Fluid Transport
Product Details
Round Stainless Steel Clad Pipes
,Fluid Transport Stainless Steel Clad Pipes
,GB/T 32958 Stainless Steel Tube
GB/T 32958 Stainless Steel Tube Stainless Steel Clad Pipes For Fluid Transport
Material, Specification, Key Features
The GB/T 32958 standard delineates the specifications and properties of Stainless Steel Clad Pipes designed for fluid transport. These pipes are constructed to endure diverse operating conditions and prove reliable in various industrial applications.
Chemical Composition (Table Presentation)
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.08 max |
| Manganese (Mn) | 2.00 max |
| Phosphorus (P) | 0.045 max |
| Sulfur (S) | 0.03 max |
| Silicon (Si) | 1.00 max |
| Chromium (Cr) | 16.0-18.0 |
| Nickel (Ni) | 10.0-14.0 |
| Nitrogen (N) | 0.10 max |
Mechanical Properties (Table Presentation)
| Property | Value |
|---|---|
| Tensile Strength | 520 MPa min |
| Yield Strength | 205 MPa min |
| Elongation | 40% min |
| Hardness (HV) | 200 max |
| Impact Toughness | 25 J min |
Steel Grade
The standard defines specific steel grades best suited for fluid transport applications, offering a balance of corrosion resistance, strength, and durability. These grades are meticulously engineered to ensure robust performance in challenging environments.
Application
The Stainless Steel Clad Pipes outlined in GB/T 32958 cater to a diverse range of fluid transport applications. From chemical processing to food industry needs, these pipes maintain product integrity while withstanding corrosive mediums and high-pressure conditions.
Possible Alternative Grades
For applications requiring specific properties or cost considerations, alternative stainless steel grades can be considered as substitutes. Depending on the project requirements and budget constraints, other grades such as ASTM A312 TP316, AISI 304L, or DIN 1.4404 might serve as viable alternatives to meet application standards.
In conclusion, GB/T 32958 stands as a comprehensive standard elucidating the critical aspects of Stainless Steel Clad Pipes for fluid transport. Through its detailed material specifications, key features, chemical compositions, mechanical properties, steel grades, applications, and alternative options, the standard provides a roadmap for selecting and utilizing stainless steel pipes effectively in various industrial sectors.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
